INSTALLING THE SOFTWARE
39
This completes the installation of the software.
• If you installed Button Manager, set up Button Manager as explained in "SETTING
UP BUTTON MANAGER" (p.42).
• If you installed Sharpdesk, the Sharpdesk setup screen will appear. Follow the
instructions in the screen to set up Sharpdesk.
Connecting a USB cable
Follow the procedure below to connect the machine to your computer.
A USB cable for connecting the machine to your computer is not included with the
machine. Please purchase the appropriate cable for your computer.
1
Insert the cable into the USB
connector on the machine.
2
Insert the other end of the cable into your computer's USB port.
• If you are using Windows Vista/7 and a security warning window
appears, be sure to click "Install this driver software anyway".
• If you are running Windows 2000/XP and a warning message
appears regarding the Windows logo test or digital signature, be sure
to click "Continue Anyway" or "Yes".
• USB is available with a PC/AT compatible computer that was
originally equipped with USB and had Windows 2000 Professional,
Windows XP, Windows Vista or Windows 7 preinstalled.
• Do not connect the USB cable before installing the printer driver. The
USB cable should be connected during installation of the printer
driver.
• If the machine will be connected using a USB 2.0 port of your
computer, please purchase a USB cable that supports USB 2.0.
• Use the machine's "HI-SPEED" mode only when using a computer
that is running Windows 2000/XP/Vista/7.
• Even when the Microsoft USB 2.0 driver is used, it may not be
possible to obtain full USB 2.0 speed if a PC card supporting USB 2.0
is used. To obtain the latest driver (which may enable a higher
speed), contact the manufacturer of your PC card.

Sharp MX-B201D Specifications

General

Duplex printing	Yes
Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	8 s
Copy speed (black, normal, US Letter)	20 cpm
Scan to	Image
Scan drivers	TWAIN
Scanner type	Flatbed scanner
Grayscale levels	256
Maximum scan area	216 x 356 mm
Scan speed (black)	20 inch/min
Image formats supported	BMP, JPG, TIF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	100
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	200 sheets
Maximum input capacity	550 sheets
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
Paper tray media weight (imperial)	15 - 21 lbs
Display	LCD
Product color	Gray
Market positioning	Business
Ethernet LAN	No
Mobile printing technologies	Not supported
Supported network protocols (IPv4)	TCP/IP, IPV4
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	12.5 W
Power consumption (average operating)	1000 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Bundled software	Sharpdesk\\r Button Manager\\r Composer
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Width	- mm
