42
SPECIFICATIONS
Machine specifications / copier specifications
(Continued)
* Type A connectors are located on the front and back right of the machine (two
connectors); however, the connectors cannot be used simultaneously on the
MX-B382. The connector on the back of the machine is not initially available for use. If
you wish to use the connector, contact your service assistance.
Continuous copying speeds*
* Copy speed during output of the second copy and following copies when performing
continuous one-sided copying of the same page (excluding offset output) using plain
one-sided paper from a tray other than the bypass tray.
Required power supply
Local voltage ±10% (For the power supply
requirements, see the name plate in the lower corner of
the left side of the machine.)
Power consumption
1.84 kW
Dimensions
MX-B382:
560 mm (W) x 493 mm (D) x 714 mm (H)
(22-3/64" (W) x 19-13/32" (D) x 28-7/64" (H))
MX-B382SC:
560 mm (W) x 494 mm (D) x 789 mm (H)
(22-3/64" (W) x 19-29/64" (D) x 31-1/16" (H))
Weight
MX-B382:
Approx. 42 kg (92.6 lbs.)
MX-B382SC:
Approx. 47 kg (103.6 lbs.)
Overall dimensions
MX-B382:
868 mm (W) x 493 mm (D) (34-11/64" (W) x 19-13/32" (D))
(when bypass tray is extended)
MX-B382SC:
1101 mm (W) x 494 mm (D) (43-11/32" (W) x 19-29/64" (D))
(when bypass tray is extended)
Copy ratio
100% / Reduced / Enlarged
A4
38 copies/min.
8-1/2" x 14", 8-1/2" x 13-1/2",
8-1/2" x 13-2/5", 8-1/2" x 13"
32 copies/min.
8-1/2" x 11", 7-1/4" x 10-1/2",
5-1/2" x 8-1/2", B5, A5, 16K
40 copies/min.
