MX-C250 SIMULATION 6 – 24
43
43-1
Purpose
Setting
Function (Purpose)
Used to set the fusing reference tempera-
ture of each operation mode.
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
NOTE:
The set value is the reference value, and it may differ from
the actual fusing temperature depending on the operating
conditions.
<Code descriptions>
Item/Display Content
Setting
range
Group
A
Group
B
Group
C
1 HL_UM READY Ready standby TH_UM set value
70 - 230 150 160 160
2 HL_UM PLAIN PAPER BW Black-White plain paper TH_UM set value
70 - 230 160 170 170
3 HL_UM PLAIN PAPER CL Color plain paper TH_UM set value
70 - 230 165 175 175
4 WARM UP END TIME Warm-up complete time
30 - 255 13 13 13
5 HL_UM PRE-JOB Resetting from preheating TH_UM set value
30 - 200 155 165 165
6 HL_UM WARMUP_120L Warm-up TH_UM set value (when the fusing temperature is under 120dgrees C)
70 - 230 155 165 165
7 HL_UM WARMUP_120H
Warm-up TH_UM set value (when the fusing temperature is 120degrees C or
above)
70 - 230 165 175 175
8 HI_WU_FM_ON_TMP
Fusing roller rotation start TH_E (when the fusing temperature in warm-up is alpha
C or above)
30 - 200 105 105 105
9 HI_WU_END_TIME
Warm-up complete time (sec) (when the fusing temperature in warm-up is alpha C
or above)
0 - 255 13 13 13
10 HI_WU_JOB_SET_TMP
Job Ready TH_UM temperature (when the fusing temperature in warm-up is alpha
C or above)
70 - 230 155 165 165
11 LO_WU_JOB_SET_TMP
Job Ready TH_UM temperature (CL) (When the fusing temperature in warming up
is under alpha degree C.)
70 - 230 155 165 165
12 HL_UM_JOB_SET_TMP_BW
Job Ready TH_UM temperature (BW) (When the fusing temperature in warming up
is under alpha degree C.)
70 - 230 150 160 160
1 HL_UM READY Ready standby TH_UM set value
70 - 230 160 165 165
2 HL_UM PLAIN PAPER BW Black-White plain paper TH_UM set value
70 - 230 170 175 175
3 HL_UM PLAIN PAPER CL Color plain paper TH_UM set value
70 - 230 175 180 180
4 WARM UP END TIME Warm-up complete time
30 - 255 13 13 13
5 HL_UM PRE-JOB Resetting from preheating TH_UM set value
30 - 200 165 170 170
6 HL_UM WARMUP_120L Warm-up TH_UM set value (when the fusing temperature is under 120dgrees C)
70 - 230 175 180 180
7 HL_UM WARMUP_120H
Warm-up TH_UM set value (when the fusing temperature is 120degrees C or
above)
70 - 230 175 180 180
8 HI_WU_FM_ON_TMP
Fusing roller rotation start TH_E (when the fusing temperature in warm-up is alpha
C or above)
30 - 200 105 105 105
9 HI_WU_END_TIME
Warm-up complete time (sec) (when the fusing temperature in warm-up is alpha C
or above)
0 - 255 13 13 13
10 HI_WU_JOB_SET_TMP
Job Ready TH_UM temperature (when the fusing temperature in warm-up is alpha
C or above)
70 - 230 165 170 170
11 LO_WU_JOB_SET_TMP
Job Ready TH_UM temperature (CL) (when the fusing temperature in warm-up is
under alpha C)
70 - 230 165 170 170
12 HL_UM_JOB_SET_TMP_BW
Job Ready TH_UM temperature (BW) (when the fusing temperature in warm-up is
under alpha C)
70 - 230 160 165 165
1 WARMUP FUMON TMP Fusing motor pre-rotation start TH_US set value (under alpha degrees)
70 - 230 150 160 160
2 WARMUP FUMOFF Preheating TH_E set value
70 - 230 160 170 170
3 HL_UM HEAVY PAPER Resetting from preheating TH_UM set value (Job Ready temperature)
70 - 230 165 175 175
4 HL_UM OHP PAPER Preheating TH_LM set value
30 - 255 13 13 13
5 HL_UM ENV PAPER Warm-up TH_UM set value (when the fusing temperature is 120C or less)
30 - 200 155 165 165
6 HL_UM GLOSS PAPER Warm-up TH_LM set value (when the fusing temperature is 120C or less)
70 - 230 155 165 165
7 HL_UM E-STAR Warm-up TH_E set value (when the fusing temperature is 120C or less)
70 - 230 165 175 175
8 HL_UM HEAVY2 PAPER Heavy paper 2 TH_UM set value
30 - 200 105 105 105
9 LO_WARMUP_TIME
The applying time in WUP TH_UM of 120dgrees C or less (Timer from completion of
warm-up)
0 - 255 13 13 13
10 HI_WARMUP_TIME
The applying time in WUP TH_UM of 120dgrees C or above (Timer from completion
of warm-up)
70 - 230 155 165 165
11 HI_WARMUP_BORDER The threshold value alpha degree C or above in warm-up.
70 - 230 155 165 165
12 JOBEND_FUMON_TIME
Fusing motor after rotation time after completion of a job (Excluding heavy paper,
OPH, and envelopes)
70 - 230 150 160 160
TH_UM Fusing upper thermister (main) HL_UM Heater lamp upper
TH_LM Fusing lower thermister (main) HL_LM Heater lamp lower
TH_E Fusing thermister (external heat roller) HL_E Heater lamp (external heat roller)
Group Destination
Group A Japan China AB_B -
Group B U.S.A. Canada Inch -
