MX-C250 SIMULATION 6 – 28
43-22
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-4) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1degree C Change
*PLAIN BW DUP APP CNT LL, PLAIN CL DUP APP CNT LL:
1count = 1 sec
Other values: 1count = 1 degree C
<Code descriptions>
Correction
value
-49 -25 -5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item/Display Content
Set-
ting
range
Group
A
Group
B
Group
C
Acc. Des-
tination
set-
ting(O/X)
1 HL_UM PLAIN BW DUP LL
(LL CORRECTION) Black-White plain paper duplex TH_UM
set value
1 - 99 55 55 55 O
2 PLAIN BW DUP APP CNT LL
(LL CORRECTION) Black-White plain paper duplex fusing
temperature application start image screen number
1 - 99 50 50 50 O
3 HL_UM PLAIN CL DUP LL
(LL CORRECTION) Color plain paper duplex TH_UM set
value
1 - 99 55 55 55 O
4 PLAIN CL DUP APP CNT LL
(LL CORRECTION) Color plain paper duplex fusing tempera-
ture application start image screen number
1 - 99 50 50 50 O
5 HL_UM HEAVY BW DUP LL
(LL CORRECTION) Black-White heavy paper duplex TH_UM
set value
1 - 99 55 55 55 X
6 HEAVY BW DUP APP CNT LL
(LL CORRECTION) Black-White heavy paper duplex fusing
temperature application start image screen number
1 - 99 50 50 50 X
7 HL_UM HEAVY CL DUP LL
(LL CORRECTION) Color heavy paper duplex TH_UM set
value
1 - 99 55 55 55 X
8 HEAVY CL DUP APP CNT LL
(LL CORRECTION) Color heavy paper duplex fusing temper-
ature application start image screen number
1 - 99 50 50 50 X
TH_UM Fusing upper thermister (center) HL_UM Heater lamp upper
TH_LM Fusing lower thermister HL_LM Heater lamp lower
TH_E Fusing thermister (external heat roller) HL_E Heater lamp (external heat roller)
Group Destination
Group A Japan China AB_B -
Group B U.S.A. Canada Inch -
Group C Europe U.K. AUS AB_A
