MX-C250 SIMULATION 6 – 27
43-21
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under high temperature and high humidity
(H/H) for the fusing temperature setting
(SIM 43-1) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1 degree C Change
*1: 1 Count = 1sec Change
<Code descriptions>
Correction
value
-49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
Item/Display Content
Set-
ting
range
Group
A
Group
B
Group
C
Acc.
Desti-
nation
set-
ting(O
/X)
1 HL_UM READY HH (HH-Correction) Ready standby TH_UM set value 1 - 99
50 50 50
X
2 HL_UM PLAIN BW HH (HH-Correction) Black-White plain paper TH_UM set value 1 - 99
50 50 50
X
3 HL_UM PLAIN CL HH (HH-Correction) Color plain paper TH_UM set value 1 - 99
50 50 50
X
4 WARMUP FUMON TMP HH (HH-Correction) Fusing motor pre-rotation start TH_UM set value 1 - 99
50 50 50
O
5 WARMUP FUMOFF HH (HH-Correction) Fusing motor pre-rotation end TH_LM set value 1 - 99
50 50 50
X
6 WARMUP END TIME HH (HH-Correction) Warm-up complete time (warm-up time (sec)) 1 - 99
50 50 50
X
7 HL_UM HEAVY HH (HH-Correction) Heavy paper TH_UM set value 1 - 99
50 50 50
X
8 HL_UM OHP HH (HH-Correction) OHP-TH_UM set value 1 - 99
50 50 50
X
9 HL_UM ENV HH (HH-Correction) Envelope TH_UM set value 1 - 99
50 50 50
X
10 HL_UM GLOSS HH (HH-Correction) Glossy paper TH_UM set value 1 - 99
50 50 50
X
11 HL_UM E-STAR HH (HH-Correction) Preheating TH_UM set value 1 - 99
50 50 50
X
12 HL_UM PRE-JOB HH
(HH-Correction)Resetting from preheating TH_UM set value (Job Ready
temperature)
1 - 99
50 50 50
X
13 HL_UM HEAVY2 CL HH Correction value for heavy paper 2 TH_UM set value under LL environment -
50 50 50
14
HL_UM WARMUP_120L
HH
(HH-Correction) Warm-up TH_UM set value (when the fusing temperature
is under 120 degrees C)
1 - 99
50 50 50
X
15 LO_WARMUP_TIME HH
(HH-Correction) Warm-up TH_UM applying time is under 120 degrees C
(Timer from completion of warm-up)
1 - 99
50 50 50
X
16
HL_UM WARMUP_120H
HH
(HH-Correction) Warm-up TH_UM applying time is 120 degrees C or above
(Timer from completion of warm-up)
1 - 99
50 50 50
X
17 HI_WU_TIME HH P applying time (timer from warm-up complete) 1 - 99
50 50 50
X
18 HI_WU_FM_ON_TMP HH
(HH-Correction) Fusing roller rotation start TH_E (when the fusing tempera-
ture in warm-up is alpha degrees C or above)
1 - 99
50 50 50
X
19 HI_WU_END_TIME HH
(HH-Correction) Warm-up complete time (sec) (when the fusing tempera-
ture in warm-up is alpha degrees C or above)
1 - 99
50 50 50
X
20
HI_WU_JOB_SET_TMP
HH
(HH-Correction) Job Ready TH_UM temperature (when the fusing tempera-
ture in warm-up is alpha degrees C or above)
1 - 99
50 50 50
X
21
HI_WARMUP_BORDER
HH
The threshold value alpha degree C or above in warm-up. 1 - 99
50 50 50
X
22
LO_WU_JOB_SET_TMP
HH
The applying time in WUP TH_UM (CL) of 120dgrees C or above (Timer
from completion of warm-up)
1 - 99
50 50 50
X
23
JOBEND_FUMON_TIME
HH
(HH-Correction) Fusing roller rotation time (sec) after completion of a job 1 - 99
50 50 50
X
24
HI_WU_JOB_SET_TMP_H
H_BW
The applying time in WUP TH_UM (BW) of 120dgrees C or above (Timer
from completion of warm-up)
1 - 99
50 50 50
X
TH_UM Fusing upper thermister (center) HL_UM Heater lamp upper
TH_LM Fusing lower thermister HL_LM Heater lamp lower
TH_E Fusing thermister (external heat roller) HL_E Heater lamp (external heat roller)
Group Destination
Group A Japan China AB_B -
Group B U.S.A. Canada Inch -
Group C Europe U.K. AUS AB_A
