MX-C250 SIMULATION 6 – 26
43-20
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environmental correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-1) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1 degree C Change
*WARMUP END TIME LL: 1count = 1sec / other correction value: 1count = 1 degree C
*The item D or F: When B5 paper, above value on item D or F is corrected “-5”
*The item G or I: When B5 paper, above value on item G or I is corrected “-5“
<Code descriptions>
Correction value -49 -25 -5 0 +5 +25 +49
Input value 1 25 45 50 55 75 99
Item/Display Content
Set-
ting
range
Group
A
Group
B
Group
C
Acc.
Destina-
tion set-
ting(O/X)
1 HL_UM READY LL (LL-Correction) Ready standby TH_UM set value
1 - 99 60 60 60
X
2 HL_UM PLAIN BW LL (LL-Correction) Black-White plain paper TH_UM set value
1 - 99 55 55 55
X
3 HL_UM PLAIN CL LL (LL-Correction) Color plain paper TH_UM set value
1 - 99 55 55 55
X
4
WARMUP FUMON TMP
LL
(LL-Correction) Fusing motor pre-rotation start TH_UM set value
1 - 99 40 40 40
O
5 WARMUP FUMOFF LL (LL-Correction) Fusing motor pre-rotation end TH_LM set value
1 - 99 50 50 50
X
6 WARMUP END TIME LL (LL-Correction) Warm-up complete time (warm-up time (sec))
1 - 99 80 80 80
X
7 HL_UM HEAVY LL (LL-Correction) Heavy paper TH_UM set value
1 - 99 55 55 55
X
8 HL_UM OHP LL (LL-Correction) OHP-TH_UM set value
1 - 99 55 55 55
X
9 HL_UM ENV LL (LL-Correction) Envelope TH_UM set value
1 - 99 55 55 55
X
10 HL_UM GLOSS LL (LL-Correction) Glossy paper TH_UM set value
1 - 99 55 55 55
X
11 HL_UM E-STAR LL (LL-Correction) Preheating TH_UM set value
1 - 99 55 55 55
X
12 HL_UM PRE-JOB LL
(LL-Correction)Resetting from preheating TH_UM set value (Job Ready
temperature)
1 - 99 55 55 55
X
13 HL_UM HEAVY2 CL LL
Correction value for heavy paper 2 TH_UM set value under LL environ-
ment
1 - 99 55 55 55
X
14
HL_UM WARMUP_120L
LL
(LL-Correction) Warm-up TH_UM set value (when the fusing tempera-
ture is under 120 degrees C)
1 - 99 55 55 55
X
15 LO_WARMUP_TIME LL
(LL-Correction) Warm-up TH_UM applying time is under 120 degrees C
(Timer from completion of warm-up)
1 - 99 50 50 50
X
16
HL_UM WARMUP_120H
LL
(LL-Correction) Warm-up TH_UM applying time is 120 degrees C or
above (Timer from completion of warm-up)
1 - 99 55 55 55
X
17 HI_WU_TIME LL P applying time (timer from warm-up complete)
1 - 99 50 50 50
X
18 HI_WU_FM_ON_TMP LL
(LL-Correction) Fusing roller rotation start TH_E (when the fusing tem-
perature in warm-up is alpha degrees C or above)
1 - 99 40 40 40
X
19 HI_WU_END_TIME LL
(LL-Correction) Warm-up complete time (sec) (when the fusing tempera-
ture in warm-up is alpha degrees C or above)
1 - 99 50 50 50
X
20
HI_WU_JOB_SET_TMP
LL
(LL-Correction) Job Ready TH_UM temperature (when the fusing tem-
perature in warm-up is alpha degrees C or above)
1 - 99 55 55 55
X
21
HI_WARMUP_BORDER
LL
The threshold value alpha degree C or above in warm-up.
1 - 99 50 50 50
X
22
LO_WU_JOB_SET_TMP
LL
The applying time in WUP TH_UM (CL) of 120dgrees C or above (Timer
from completion of warm-up)
1 - 99 55 55 55
X
23
JOBEND_FUMON_TIME
LL
(LL-Correction) Fusing roller rotation time (sec) after completion of a job
1 - 99 50 50 50
X
24
HI_WU_JOB_SET_TMP_L
L_BW
The applying time in WUP TH_UM (BW) of 120dgrees C or above (Timer
from completion of warm-up)
1 - 99 60 60 60
X
TH_UM Fusing upper thermister (center) HL_UM Heater lamp upper
TH_LM Fusing lower thermister HL_LM Heater lamp lower
TH_E Fusing thermister (external heat roller) HL_E Heater lamp (external heat roller)
Group Destination
Group A Japan China AB_B -
Group B U.S.A. Canada Inch -
Group C Europe U.K. AUS AB_A
