MX-C250 SIMULATION 6 – 79
82 1 - 3 Adjustment value Time setting before dialing
(20PPS)
50ms 0 0 0
60ms 0 0 1
70ms 0 1 0
80ms 0 1 1
90ms 1 0 0
100ms 1 0 1
110ms 1 1 0
120ms 1 1 1
4 - 6 Adjustment value Time setting before dialing (DTMF) 30ms 0 0 0
40ms 0 0 1
50ms 0 1 0
60ms 0 1 1
70ms 1 0 0
80ms 1 0 1
90ms 1 1 0
100ms 1 1 1
7, 8 Not used
83 1 - 4 Adjustment value Setting of DTMF send level (high
group)
Setting range
0(0dBm) - 15 (-15dBm)
1dBm intervals
Two states input
5 - 8 Adjustment value Setting of DTMF send level (low
group)
Setting range
0(0dBm) - 15 (-15dBm)
Two states input
84 1 - 4 Adjustment value Setting of DTMF send maximum
level (high group)
Setting range
0(0dBm) - 15 (-15dBm)
Two states input
5 Adjustment value Setting of DTMF send level (low
group adjustment)
0 : 0.5dBm adjustment OFF 1 : 0.5dBm adjustment ON
6 Adjustment value Setting of DTMF send level (high
group adjustment)
0 : 0.5dBm adjustment OFF 1 : 0.5dBm adjustment ON
7 Adjustment value Polar reverse check when calling 0 : OFF 1 : ON
8 Not used
85 1, 2 Busy tone detec-
tion
Report output (when sending the
data)
Do not change 0 0
Not used 0 1
Not used 1 0
Not used 1 1
3, 4 Setting External line on-hook time 100ms 0 0
200ms 0 1
300ms 1 0
400ms 1 1
5 Setting External line on-hook detection 0 : Photo coupler 1 : Line voltage
6, 7 Setting External line on-hook detection
threshold with Line voltage
16V 0 0
18V 0 1
20V 1 0
22V 1 1
8 DPMUTE control 0 : OFF 1 : ON
86 1 - 4 Adjustment value DPMUTE time afte dialing X(ms) = ( N * 5 ) + 5 Two states input
5 - 8 Adjustment value The interval till the next call after
finishing the communication
Setting range
0 - 15s
Two states input
87 1 Adjustment value Manual calibration 0 : Perform manual calibration 1 : Does not perform man-
ual calibration
Two states input
2, 3 Adjustment value External line off-hook detection
time under the simulated voltage
addition
50ms 0 0
100ms 0 1
200ms 1 0
300ms 1 1
4 - 8 Not used
88-
89
Not used
90 1 - 8 Adjustment value Minimum cycle of CI signal CI signal maximum cycle +1 to
255 ms(1ms interval)
Two states input
91 1 - 8 Adjustment value Maximum cycle of CI signal 12 to 254 ms(1ms interval) Two states input
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
