Sharp MX-C300F User Manual

MX-C250 DISASSEMBLY AND ASSEMBLY 10 – 27
G.Manual paper feed section
(1) Paper feed roller
1) Remove the maintenance cover.
2) Remove the E ring, and remove the paper feed roller.
(2) Separation roller, Torque limiter
1) Remove the separation roller cover
2) Remove the separation roller assembly.
3) Remove the separation roller and the torque limiter.
Parts
1 Paper feed roller
2 Separation roller
3
Torque limiter

Sharp MX-C300F Specifications

General

Brand	Sharp
Model	MX-C300F
Category	All in One Printer
Language	English
