MX-C250 DISASSEMBLY AND ASSEMBLY 10 – 29
4) Remove the right door paper in roller and the right door paper
out roller from the shafts.
(2) Paper exit unit
a.Paper exit auxiliary roller
1) Remove the knob, the earth plate, E rings and pressure
springs.
2) Remove the paper exit auxiliary roller unit.
3) Remove the paper exit auxiliary roller.
b.Paper exit roller
1) Remove the knob.
2) Remove the paper exit gear unit, and remove the paper exit
roller unit.
Parts
1 Paper exit auxiliary roller
2 Paper exit roller
3 Discharge brush
