MX-C250 SIMULATION 6 – 18
25-4
Purpose
Operation test/check
Function (Purpose)
Used to display the toner control correction
value.
Section
Process (Developing section)
Operation/Procedure
1) Select the color with 10 keys.
2) Press [OK]/[START] key.
25-5
Purpose
Operation test/check
Function (Purpose)
Used to display the toner supply amount
detection system value.
Section
Process (Developing section)
Operation/Procedure
1) Select the color with 10 keys.
2) Press [OK]/[START] key.
Color displayed items Contents
Mini-
mum
Max
K
YLD_CNT_FB
Toner supply FB ratio
by yield count
50
200
DELTA_DVB
⊿DVB(Process control
DVB-ideal DVB)
-500 500
IDL_DVB Ideal DVB 100 600
PROCON_DVB Process control DVB 0 600
DV_LIFE Developer life area 1 32
COVERAGE_AREA Average coverage area 1 29
ENV_AREA Environmental area 1 16
MULTI_TIME
Accumulated driving
time area
18
PRO_FB_CNT
Process control feed-
back toner supply
remaining number of
times
0
655
35
PRO_FB_INT
Process control feed-
back toner supply inter-
val
0
655
35
PRO_FB_RATIO
Process control feed-
back toner supply ratio
-127 127
RECV_MODE_CNT(+)
The number of times of
recovery mode (+)
0
655
35
RECV_MODE_CNT(-)
The number of times of
recovery mode (-)
0
655
35
C
YLD_CNT_FB
Toner supply FB ratio
by yield count
50
200
DELTA_DVB
⊿DVB(Process control
DVB-ideal DVB)
-500 500
IDL_DVB Ideal DVB 100 600
PROCON_DVB Process control DVB 0 600
DV_LIFE Developer life area 1 32
COVERAGE_AREA Average coverage area 1 29
ENV_AREA Environmental area 1 16
MULTI_TIME
Accumulated driving
time area
18
PRO_FB_CNT
Process control feed-
back toner supply
remaining number of
times
0
655
35
PRO_FB_INT
Process control feed-
back toner supply inter-
val
0
655
35
PRO_FB_RATIO
Process control feed-
back toner supply ratio
-127 127
RECV_MODE_CNT(+)
The number of times of
recovery mode (+)
0
655
35
RECV_MODE_CNT(-)
The number of times of
recovery mode (-)
0
655
35
M
YLD_CNT_FB
Toner supply FB ratio
by yield count
50
200
DELTA_DVB
⊿DVB(Process control
DVB-ideal DVB)
-500 500
IDL_DVB Ideal DVB 100 600
PROCON_DVB Process control DVB 0 600
DV_LIFE Developer life area 1 32
COVERAGE_AREA Average coverage area 1 29
ENV_AREA Environmental area 1 16
MULTI_TIME
Accumulated driving
time area
18
PRO_FB_CNT
Process control feed-
back toner supply
remaining number of
times
0
655
35
PRO_FB_INT
Process control feed-
back toner supply inter-
val
0
655
35
PRO_FB_RATIO
Process control feed-
back toner supply ratio
-127 127
RECV_MODE_CNT(+)
The number of times of
recovery mode (+)
0
655
35
RECV_MODE_CNT(-)
The number of times of
recovery mode (-)
0
655
35
Y
YLD_CNT_FB
Toner supply FB ratio
by yield count
50
200
DELTA_DVB
⊿DVB(Process control
DVB-ideal DVB)
-500 500
IDL_DVB Ideal DVB 100 600
PROCON_DVB Process control DVB 0 600
DV_LIFE Developer life area 1 32
COVERAGE_AREA Average coverage area 1 29
ENV_AREA Environmental area 1 16
MULTI_TIME
Accumulated driving
time area
18
PRO_FB_CNT
Process control feed-
back toner supply
remaining number of
times
0
655
35
PRO_FB_INT
Process control feed-
back toner supply inter-
val
0
655
35
PRO_FB_RATIO
Process control feed-
back toner supply ratio
-127 127
RECV_MODE_CNT(+)
The number of times of
recovery mode (+)
0
655
35
RECV_MODE_CNT(-)
The number of times of
recovery mode (-)
0
655
35
Color
displayed
items
Contents
Min-
imu
m
Max
K
TCS_B_AVE
.
Toner sensor output block average
value
0 255
TSG_HUM
Current TSG environment correction
value (middle speed)
-
127
127
TSG_COV
Current TSG print rate correction
value (middle speed)
-
127
127
TSG_LIFE
Current TSG developer life correc-
tion value (middle speed)
-
127
127
TSG_ENV
Current TSG cumulative drive area
correction value (middle speed)
-
127
127
DELTA_TSG Average coverage area
-
254
254
DELTA_TSG Operation voltage correction value 1 255
TSG_TOTAL
Operation voltage target value (Mid-
dle speed)
0 255
TCS_AVE. Toner sensor output average value 0 255
