Sharp MX-M1204 User Manual

Maintenance
SHARP Document Solution Centre
19
Interval Checklist
500k 1000k 3000k Paper Feed & Transport (Cont’d)
x x Replace Transport Drive Clutch MFTFC [PCLC-0355FCZZ] when Manual
Feed (MFT) counter reaches 3000K
x x Replace Transport Drive Clutch LCCPFC [PCLC-0354FCZZ] when LCC
Paper Feed counter reaches 3000K
x x Replace Multi Stage Drive B Clutch VPTC1 [PCLC-0357FCZZ] when Tray
3 & Tray 4 total paper feed counter reaches 3000K
x x Replace Tandem Drive Clutch VPTC2 [PCLC-0354FCZZ] when Tray 3 &
Tray 4 total paper feed counter reaches 3000K
x x Replace Tandem Drive Clutch VPTC3 [PCLC-0354FCZZ] when Tray 2,
Tray 3 & Tray 4 total paper feed counters reaches 3000K
Duplex Section
Replace ADU Decurler Roller [NROLR1934FCZZ],
x x Replace ADU Paper Feed Roller [NROLR1685FCZZ], ADU Transport
Roller [NROLR1687FCZZ x 3] & ADU Side Transport Roller
[NROLR1686FCZZ x 2] when ADU counter reaches 3000K
x x Replace ADU Solenoid [RPLU-0353FCPZ] when ADU counter reaches
3000K
x x Replace ADU Switch Gate [PGIDM2346FCZZ], ADU Reverse Gate
[PGIDM2347FCZZ], Delivery Reverse Gate [PGIDM2362FCZZ] &
Reverse ADU Switch Gate [PGIDM2363FCZZ] when ADU counter
reaches 3000K.
Note: Paper Feed Tray Counters can be viewed using Sim 22-09.
Sim 24-04 Clear PS PAPER Counter
(only when Paper Dust Removal Kit is replaced)
MX-MF11 Bypass Tray for 2 Tray LCT
Check/Clean Manual Feed Rollers - Replace when Manual Feed
counter reaches 200k:- [0PQAF030080// x 1, 0PQAF031081// x 1,
0PQAF032080// x 1]
MX-CF11 Inserter
Check/Clean Inserter Pick Up Roller, Separation Roller & Feed Belt -
Replace when Individual Inserter Feed (Tray1 & Tray 2) counters reach
60k :- [0PQB4772225// x 1, 0PQA8061295A/ x1, 0PQA8592241// x 1]
Clean Drive & Follower Rollers
MX-FN24 Finisher, MX-FN25 Saddle Finisher (90cpm only)
Check/Replace the Offset Tray Drag (Shift Sponge) Rollers when the
Total Counter reaches 500k [0PPB4783503// x 2]
Check/Replace Staple Unit (edge binding) when Staple Counter
reaches 500k [0PPAJ011015//]
Check/Replace Saddle Staple Unit (centre binding) when Saddle Staple
Counter reaches 200k [0PPB7007852// x 1 set]
x x Check the Shift (Positioning) Roller when the Total Counter reaches
2500K – replace if worn [0PPB4082435// x 1]
