SHARP Document Solution Centre
41
Only limited data that is stored on the SD Card can be backed up and reinstalled following replacement or
SD card failure. If the SD Card is operating normally before replacement, backup the data (prior to
replacing).
The SD Card includes the following data:-
Partition
Number
Stored Data
Backup
Method
Data
Reinstall
Method
L-201
ICU firmware
data
ICU firmware
-
SIM49-01
(BOOT
cannot be
installed
again.)
I-201
FAX reception
data
FAX/Internet Fax reception image data
SIM66-62 -
Replacement Procedure:
When replacing the SD card, be sure to use the specified SD card supplied as a service part only.
The firmware required for booting the MFP device must be included on the SD card that is used in
this machine - Commercially available SD cards do not have this firmware data.
1. When there is FAX/Internet Fax data received, use SIM66-62 to back up the image data to the USB
memory (PDF file type), and then provide the PDF data to the user. (The data cannot be restored to
the machine.)
2. Replace the SD card with a new one.
3. Upgrade the firmware to the latest version.
4. Use SIM66-10 to clear the image send memory. (This is in order to obtain consistency between
the HDD data and the image related memory.)
Notes:
• If E7-07 trouble occurs and the error cannot be cancelled using SIM16, this may indicate an issue
or failure of the SD Card – replace the SD Card by following the procedure detailed above.
