Coin Vend Interface
24
SHARP Document Solution Centre
Connector Signals
Pin No. PCU PWB (CN12)
1 + 24v Out
2 GND Out
3 CV_B/W_COPY In
4 CV_COUNT Out
5 CV_START Out
6 CV_CA Out
7 CV_COLOUR_ COPY In
8 CV_COLOUR1 Out
9 CV_STAPLE Out
10 CV_COLOUR0 Out
11 CV_DUPLEX Out
12 5v Out
13 CV_SIZE0 Out
14 CV_SIZE1 Out
15 CV_SIZE2 Out
16 CV_SIZE3 Out
Colour Signals
Colour Mode (CL-COLOR1) (CL-COLOR0)
B/W 0 0
Full Colour 1 1
Others
(Single/Two Colour)
0 1
Paper Size Signals
SIZE3 SIZE2 SIZE1 SIZE0 PAPER SIZE
0 0 0 0 NIL
0 0 0 1 A3
1 0 1 1 A3W
0 0 1 0 A4
0 0 1 1 LT
0 1 0 0 B4
0 1 0 1 LG
0 1 1 0 WLT
0 1 1 1 INV
1 0 0 0 B5
1 0 1 0 A5
1 0 0 1 EXTRA
