MX-M200D ELECTRICAL SECTION 13-9
3. Signal name list
Category Signal name Name(Type) Function/Operation
Connector level
Connector
No.
Pin
No.
PWB
name
Note
"L" "H"
LD INT5V Interlock 5V power LSU PWB power that turns
off electricity when interlock
SW is OFF
— — CN703 5 MCU
LD /SYNC LSU horizontal sync
signal
Horizontal sync detection
signal of LSU laser (481uS
cycle)
Detection — CN703 7 MCU
Sensor TCS Toner density sensor
(Magnetic sensor)
Detects the toner density — — CN27 2 MCU Analog
DEV DVSEL Pprocess unit
detection
Detects installation of the
process unit
Ye s No CN27 3 MCU
FAX /FAXDET FAX option installation
detection
Detects installation of the
FAX option
With FAX No FAX CN41 26 MCU
FAX /FAX_RST FAX option hard reset Resets FAX PWB Reset — CN41 20 MCU
FAX /FAXWU FAX activate request
signal
Activate request signal of
return from energy-saving
by FAX incoming
Activate
request
— CN41 29 MCU
IMC /OP_RST IMC hard reset signal Detects installation of the
IMC2
With IMC No IMC CN33 5 MCU
IMC /ESDET IMC installation
detection signal
Resets IMC2 PWB Reset — CN34 6 MCU
LD /LD_ENB Laser control signal ON/OFF for APC control ON OFF CN703 4 MCU
Clutch SPFCLH SPF clutch SPF paper feed clutch
control
OFF ON CN9 21 MCU
Sensor /SPFCOVER SPF cover open/close
sensor (Transmission
type)
Detects open/close of SPF
document transport cover
OPEN CLOSE CN9 16 MCU
Sensor SPFOPEN SPF book sensor
(Transmission type)
Detects unfinished closing
(separation) of SPF
OPEN CLOSE CN9 18 MCU
Sensor POUT Entry port sensor
(Transmission type)
Detects paper transport — Paper no
empty
CN26 3 MCU
Sensor PDPX Duplex sensor
(Transmission type)
Detects paper transport Paper no
empty
— CN26 7 MCU
Sensor /LFTHP Job separator home
position sensor
Job separator home
position sensor
Home
position
— CN26 19 MCU
Sensor /TRAY_D Tray full space sensor
(Transmission type)
Detects full space of paper
tray
Paper no
empty
— CN26 18 MCU
Sensor /TRAY_FULL Upper tray full space
sensor (Transmission
type)
Detects full space of paper
tray
Full — CN26 17 MCU
Sensor /JOBS_DLD Job separator lower
limit position detection
switch (SW)
Detects lower limit position
of job separator
Detection — CN26 8 MCU
Sensor SFTHP Shifter home position
sensor (Transmission
type)
Home position sensor of
shifter
Home
position
— CN26 4 MCU
Sensor /SPFPOUT SPF paper exit sensor
(Transmission type)
Paper pass sensor of
document exit in SPF
Paper no
empty
— CN9 19 MCU
Sensor SPFPAPER SPF paper pass
sensor (Transmission
type)
Paper pass sensor of SPF — Paper no
empty
CN9 25 MCU
Sensor MHPS Mirror home position
sensor (Transmission
type)
Home position sensor of
scanner mirror unit
— Home
position
CN10 2 MCU
Sensor CASETTE 1st tray open/close
switch (SW)
Detects open/close of 1st
tray
OPEN CLOSE CN14 1 MCU
Sensor PIN Paper entry sensor
(Transmission type)
Detects paper transport — Paper no
empty
CN20 2 MCU
Sensor HPEMPTY Manual paper tray
paper empty sensor
(Transmission type)
Detects manual paper Paper no
empty
— CN17 2 MCU
Sensor CPEMPTY 1st tray paper empty
sensor (Transmission
type)
Detects paper empty of 1st
tray
— Paper no
empty
CN18 2 MCU
Sensor RTH_IN Fusing thermistor
(Thermistor)
Thermistor signal for fusing
temperature detection
— — CN25 1 MCU Analog
