MX-M182 SIMULATIONS 7-11
09 01 Duplex motor forward rotation check
Used to check the duplex motor rotation.
The duplex motor is rotated in the normal direction (paper exit direction) for 30sec.
After completion of the process, the machine shifts to the sub code input window.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Interrupts the output operation, and shifts to the sub code input window.
(Execution is not
allowed when
DUPLEX setting is
OFF.)
02 Duplex motor reverse rotation check
Used to check the duplex motor reverse rotation.
The duplex motor is rotated in the reverse direction for 30sec.
After completion of the process, the machine shifts to the sub code input window.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Interrupts the output operation, and shifts to the sub code input window.
(Execution is not
allowed when
DUPLEX setting is
OFF.)
04 Duplex motor RPM adjustment
Used to adjust the duplex motor rotation speed.
When this simulation is executed, the following setting window is displayed. Enter an input value with
numeric keys and press [OK] key or [START] key.
The setting range is in 1-13 steps.
When a value outside the setting range is inputted, it is ignored.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shift to the sub code input window.
Default:
4
05 Duplex motor switchback time adjustment
Used to adjust the duplex motor switchback time when the motor reverse rotation is controlled.
When this simulation is executed, the following setting window is displayed. Enter an input value with
numeric keys and press [OK] key or [START] key.
The setting range is 50-76.
When the adjustment value is increased by 1, the distance up to reverse start is increased by 3 steps in 1-2
phase excitement.
When a value outside the setting range is inputted, it is ignored.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shift to the sub code input window.
Default:
50
Main
code
Sub
code
Contents Remark
Sim9-1 DMF CHECK
PRESS OK KEY EXEC
Sim9-1 DMF CHECK
EXEC
[OK] key or [START] Key
(Execution start window) (Execution window)
Sim9-2 DMR CHECK
PRESS OK KEY EXEC
Sim9-2 DMR CHECK
EXEC
[OK] key or [START] Key
(Execution start window) (Execution window)
Sim9-4 MOTOR SPEED
4
4[ 1-13]
1:MOTOR SPEED
(Setting window)
• 18cpm/20cpm machine:
Set value : Speed (PPS)
01 : 637.2PPS (Slow)
02 : 640.4PPS
03 : 643.6PPS
04 : 646.9PPS
05 : 650.1PPS
06 : 653.3PPS
07 : 656.5PPS
08 : 659.8PPS
09 : 662.9PPS
10 : 666.2PPS
11 : 669.4PPS
12 : 672.6PPS
• 23cpm machine:
Set value : Speed (PPS)
01 : 760.2PPS (Slow)
02 : 764.1PPS
03 : 768.0PPS
04 : 771.8PPS
05 : 775.7PPS
06 : 779.5PPS
07 : 783.3PPS
08 : 787.2PPS
09 : 791.0PPS
10 : 794.8PPS
11 : 798.6PPS
12 : 802.5PPS
Sim9-5 SW BACK TIME
50
50[ 50-76]
1:SW BACK TIME
To Next Page
