Sharp MX-M202D Service Manual

MX-M182 MAINTENANCE 9-1
[9] MAINTENANCE
1. Maintenance table
X:Check(Clean, adjust, or replace when required.) O:Clean :Replace :Adjust :Lubricate
*1: Recommendable replacement time:50K(A4, 6%print)
*2: In maintenance cycle, after beginning to use each paper feed counter 100K, one year is a standard. Exchange when worn out.
*3: Maintenance cycle is RSPF document FEED value 100K (Sim.22-8). Or, after it begins to use it, one year is a standard. When worn out, it
exchanges it.
Unit name Part name
When
calling
50K 100K 150K 200K 250K Remark
Drum peripheral
OPC drum -
Cleaning blade -
Side seal F/R X X X X X X
MC unit X
(MC charging electrode) - ( ) ( ) ( ) ( ) ( ) Exchange if necessary
(MC grid) - ( ) ( ) ( ) ( ) ( ) Exchange if necessary
(MC case) - ( ) ( ) ( ) ( ) ( ) Exchange if necessary
Transfer wire O O O O O O
Transfer paper guide O O O O O O
MC guide seal (Cleaning
blade)
-
Drum fixing plate B X
Separation pawl X
Star ring N2
Star ring  5
Pawl holder PAN
Process frame unit X X X X X
Discharge holder O O O O O O
Developing
section
Developer X
DV seal X X X X X
Toner density sensor X X X X X X Check the sensor head surface.
DV side seal F/R X X X X X X
Optical section
Reflector O O O O O O
Mirrors - O O O O O
Pulley - X X X X X
CCD Lens - O O O O O
Table glass O O O O O O
White Plate O O O O O O
Drive wire - X X X X X
Rail - X X X X X
OC O O O O O O
LSU
Dust-proof glass O O O O O O
Paper feed
section
Manual feed take-up roller O O O O O O *2
Alcohol cleaning
Transport rollers O O O O O O *2
Alcohol cleaning
Spring clutch - O O O O O
Electromagnetic clutchs - X X X X X
Fusing section
Upper heat roller X O O O O
Pressure roller X O O O O O
Pressure roller bearing - X X O O O
Upper separation pawl X X X O O O
Lower separation pawl X X X O O O
Cleaning pad X X X X X
Drive section
Gears - X X X X X
Belts - X X O X X
Paper exit section
VOC filter - *1
Document
transport section
Pickup roller O O O O O O *3
Handling unit X X X X X X *2
Handling sheet X X X X X X
Paper feed roller O O O O O O *3
PS roller O O O O O O
Transport roller X X X X X X
Paper exit roller X X X X X X
Cassette paper
feed section
Paper feed roller X X X X X *2
Handling unit X X X X X X
Handling sheet X X X X X *2

Sharp MX-M202D Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.2 s
Scanner type	-
Maximum scan area	Legal (216 x 356) mm
Maximum scan resolution	- DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Maximum duty cycle	- pages per month
Page description languages	PCL 6, PostScript 3
Total input capacity	- sheets
Maximum input capacity	1100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Transparencies
Paper tray media weight	56 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A6
Maximum ISO A-series paper size	A4
Display	LED
Product color	White
Market positioning	Business
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
Wi-Fi	No
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	1200 W
Windows operating systems supported	Windows 2000, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Bundled software	Scanner utility software

Weight and Dimensions

Depth	573 mm
Width	591 mm
Height	595 mm
