ENGLISH
E-9
MODE-ON / OFF button See Page E-12
Sensor sensitivity select switch
Filter Reset Button
Odor Sensor
Sensor Cover
Dust Sensor
Main Unit
Filter Frame
True HEPA Filter (white)
See Page E-18
Washable Active Carbon Filter (black)
See Page E-16
Filter Separator
Pre-Filter
Front Panel
Tab
Remote Control
See Page E-14
SENSOR
NORMAL
SENSITIVE
FILTER RESET
Handle
Air Outlet
Power Cord
Power Plug
BACK
Purified Air Louver
• The purified air discharge can be changed
to the directions indicated by the arrows as
desired.
INCLUDED
Remote Control (1 unit) Battery (AA battery X 2)
• Operation Manual
PART NAMES
To Next Page
