Menu Items
SCAN MODE (AV input)
SetsthescanmodeusedforAVmodeinput.
MODE1 ...............Over-scandisplay
MODE2 ...............Under-scandisplay
MODE3 ...............Under-scandisplaywhentheinputsignal
is1080i/p.Otherwise,over-scandisplay
*
EvenwhenMODE1isselected,under-scandisplayisusedwhen
theinputsignalis1080i/pandthescreensizeisDotbyDot.
POWER MANAGEMENT
POWERMANAGEMENTdetermineswhetherornotto
switch modes from no signal to the input signal standby
mode.
COLOR SYSTEM (AV S-VIDEO/AV VIDEO)
SelectthecolorsystemoftheAVequipmentwhichis
connectedtoAVS-videoandAVvideoinputterminal.(AUTO
/PAL/PAL-60/SECAM/NTSC3.58/NTSC4.43)
WhenAUTOisselected,thecolorsystemisautomatically
set according to the input signal.
AUDIO OUTPUT (RCA)
Sets the volume of sound output from the audio output
terminals.
WhensettoVARIABLE2,soundwillnotbeoutputfromthe
built-inspeakerortheexternalspeakerterminal.
VARIABLE1 ........ YoucanadjustthevolumeusingVOLUME.
VARIABLE2 ........ YoucanadjustthevolumeusingVOLUME.
FIXED .................Fixesthesounds.
AUDIO LEVEL (STEREO MINI)
Selects the maximum audio input level of the audio input
terminal.
SELF ADJUST
On a PCD-SUB/PCRGB screen, specify whether to
performscreenadjustmentautomaticallyornot.WhenON
isselected,thescreenisautomaticallyadjustedwhenits
resolutionis800x600orhigherandthetimingofinput
signalschanges.“ADJUSTING”appearsonthescreen
duringtheadjustment.Forimageswithblackedges,etc.,
dependingonthesignal,adjustmentmaynotbepossible.
InthiscaseselectOFF.(Performmanualadjustmentofthe
screen.)
AUTO INPUT CHANGE
Specifywhethertochangeinputsautomatically.WhenONis
selected and no signal is present in the selected input mode,
AUTOINPUTCHANGEautomaticallychangestheselected
mode to another mode where a video signal is present.
Whenvideosignalsexistinmultipleinputmodes,the
switching priority is as follows:
PCD-SUB,PCHDMI,AVHDMI,AVCOMPONENTandAV
VIDEO
WhenthePN-ZB01(optional)isattached:
PCDVI-D,PCHDMI,PCD-SUB,PCRGB,AVDVI-D,AV
HDMI,AVCOMPONENT,AVS-VIDEOandAVVIDEO
(Inputmodeswitchingmaytake15secondsormore,
dependingontheconnectedequipment.Inputsignals
may not be detected properly and a priority may change,
dependingontheconnectedequipmentorvideosignals.)
n
MULTI
ENLARGE (See page 26.)
Sets whether or not to use the enlarge function.
ADVANCED (ENLARGE)
ENLARGEH/ENLARGEV
.........Setsthenumberofscreensplits(numberof
monitors)inthehorizontal/verticaldirectionusedfor
the enlargement.
ENLARGE-POS
......... Specify the split screen to be displayed when the
enlargement function is used.
H-POS/V-POS
.........Adjustthehorizontal/verticalpositionofthe
enlarged screen.
BEZEL ADJUST
Sets whether or not to use the frame correction function.
ADVANCED (BEZEL ADJUST)
BEZELADJUST(TOP)/BEZELADJUST(BOTTOM)/
BEZELADJUST(RIGHT)/BEZELADJUST(LEFT)
.........Adjustssothatthetop/bottom/left/rightconnecting
jointsofgroupedunitswillbedisplayedsmoothly
when a group of monitors are aligned in multiples to
display a single image.
BEZEL(TOP)/BEZEL(BOTTOM)/BEZEL(RIGHT)/
BEZEL(LEFT)
......... Sets the frame width of the display.
