Sharp PN-E702 - OPTION menu commands

38
E
Controlling the Monitor with a PC (RS-232C)
OPTION menu
Function Command Direction Parameter Reply Control/Response contents *1
*2
(A) (B)
DATE/TIMESETTING DATE WR AABBCCDDEE AABBCCDDEE AA:Year,BB:Month,CC:Day,DD:Hour,EE:Minute
○ ○ ○
DATEDISPLAYFORMAT DTFT WR 0-2 0-2 0:YYYY/MM/DD,1:MM/DD/YYYY,2:DD/MM/YYYY
YYYY:Year,MM:Month,DD:Day
TIMEDISPLAYFORMAT TMFT WR
0-1 0-1 0:24-HOURTIME,1:12-HOURTIME
SCHEDULE SC01-
SC08
WR ABCDEFFGGH ABCDEFFGGH Scheduleofaspeciednumber
A:Schedule 0=Noteffective,1=Effective
B:Power 0=OFF,1=ON
C:Dayoftheweek1 0=Onlyonce,1=Everyweek,2=Everyday
D:Dayoftheweek2 0=Sunday,1=Mondaythrough6=Saturday,
 9=Notexist
E:Dayoftheweek3 0=Sunday,1=Mondaythrough6=Saturday,
 9=Notexist
F:Hour 00-23
G:Minute 00-59
H:Input 0=Notspecied,1=PCDVI-D/AVDVI-D,
2=PCD-SUB,3=PCRGB/AVCOMPONENT,
4=AVVIDEO,5=AVS-VIDEO,
6=PCHDMI/AVHDMI
“ERR”whenLOWPOWERisselectedforSTANDBYMODE.
SCHEDULEBRIGHTNESS SB01-
SB08
WR 0-31 0-31 Screen brightness to change
99 99 Disablebrightnesssetting
INPUTSELECT DVI DVSL WR 0-1 0-1 0:PCDVI-D,1:AVDVI-D
○
-
○
BNC BNSL WR 0-1 0-1 0:PCRGB,1:AVCOMPONENT
○
-
D-SUB SLDS WR 0-2 0-2 0:PCD-SUB,1:AVCOMPONENT,2:AVVIDEO
○ ○
HDMI HDSL WR 0-1 0-1 0:PCHDMI,1:AVHDMI
○ ○
AUDIOSELECT PCDVI-D ASDP WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA)
○
-
PCHDMI ASHP WR 0-1 0-1 0:HDMI,1:AUDIO(STEREOMINI)
○
2-3 2-3 2:AUDIO1(RCA),3:AUDIO2(RCA) -
PCD-SUB ASAP WR 1-3 1-3 1:AUDIO(STEREOMINI)
○
2:AUDIO1(RCA),3:AUDIO2(RCA) -
PCRGB ASCP WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -
AVDVI-D ASDA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -
AVHDMI ASHA WR 0-1 0-1 0:HDMI,1:AUDIO(STEREOMINI)
○
2-3 2-3 2:AUDIO1(RCA),3:AUDIO2(RCA) -
AVCOMPONENT
(BNC)
ASCA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA)
-
AVCOMPONENT
(D-SUB)
ASC2 WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA)
○
AVS-VIDEO ASSA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -
AVVIDEO(BNC) ASVA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -
AVVIDEO(D-SUB) ASV2 WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA)
○
INPUT
RESOLUTION
(PC)
RESOLUTIONCHECK PXCK R - Returns current resolution in the form of hhh, vvv.
-
○ ○
PIXELSETTING
(PCD-SUB,PC
RGB)
PXSL WR 1 1 768)1360x768
2 2 768)1280x768
3 3 768)1024x768
5 5 480)848x480
6 6 480)640x480
7 7 1050)1680x1050
8 8 1050)1400x1050
9 9 768)AUTO
10 10 480)AUTO
INPUTRESOLUTION(AV) RESOLUTIONCHECK RESO R - 480i,480p,1080i,720p,1080p,VGA,etc. -
ZOOM2SPECIALSETTING
(PCD-SUB,PCRGB)
Z2SP WR 0-1 0-1 0:OFF,1:ON
○
SCANMODE SCAN WR 0-2 0-2 0:MODE1,1:MODE2,2:MODE3(WhentheinputmodeisAV)
○
POWERMANAGEMENT(PC) PMNG WR 0-1 0-1 0:OFF,1:ON
○
POWERMANAGEMENT(AV) PMAV WR 0-1 0-1 0:OFF,1:ON
○
COLORSYSTEM CSYS WR 0-5 0-5 0:AUTO,1:PAL,2:PAL-60,3:SECAM,4:NTSC3.58,5:NTSC4.43
○
AUDIOOUTPUT(RCA) AOUT WR 0-2 0-2 0:VARIABLE1,1:FIXED,2:VARIABLE2
○
AUDIOLEVEL(STEREOMINI) AIVP WR 0-1 0-1 0:1.0Vrms,1:0.5Vrms
○
SELFADJUST AADJ WR 0-1 0-1 0:OFF,1:ON
○
AUTOINPUTCHANGE AINC WR 0-1 0-1 0:OFF,1:ON
○
