Specications
n
DDC (plug and play)
The monitor supports the VESA DDC (Display Data Channel) standard.
DDC is a signal standard for plug and play between monitors and computers. Information about resolution and other parameters
is exchanged between the two. This function can be used if the computer supports DDC and it has been congured to detect
plug-and-play monitors.
There are several types of DDC, depending on the communication method used. This monitor supports DDC2B.
n
Compatible signal timing (PC)
Screen resolution Hsync Vsync Dot frequency
Digital
Analog (D-SUB)
HDMI
VESA 640 × 480 31.5kHz 60Hz 25.175MHz Yes Yes
800 × 600 37.9kHz 60Hz 40.0MHz Yes Yes
848 × 480 31.0kHz 60Hz 33.75MHz - Yes
1024 × 768 48.4kHz 60Hz 65.0MHz Yes Yes
1280 × 800 49.7kHz 60Hz 83.5MHz Yes Yes
1280 × 960 60.0kHz 60Hz 108.0MHz Yes Yes
1280 × 1024 64.0kHz 60Hz 108.0MHz Yes Yes
80.0kHz 75Hz 135.0MHz Yes Yes
1360 × 768 47.7kHz 60Hz 85.5MHz Yes -
1400 × 1050 65.3kHz 60Hz 121.75MHz Yes -
1440 × 900 55.9kHz 60Hz 106.5MHz Yes Yes
1680 × 1050 65.3kHz 60Hz 146.25MHz Yes Yes
Wide 3840 × 2160 54.0kHz 24Hz 297.0MHz Yes -
56.25kHz 25Hz 297.0MHz Yes -
67.5kHz 30Hz 297.0MHz Yes -
112.5kHz 50Hz 594.0MHz Yes -
135kHz 60Hz 594.0MHz Yes -
4096 × 2160
*1
54.0kHz 24Hz 297.0MHz Yes -
56.0kHz 25Hz 297.0MHz Yes
*2
-
67.0kHz 30Hz 297.0MHz Ye s
*2
-
112.5kHz 50Hz 594.0MHz Yes -
135.0kHz 60Hz 594.0MHz Yes -
1280 × 720 44.7kHz 60Hz 74.4MHz Yes Yes
1920 × 1080 67.5kHz 60Hz 148.5MHz Yes Yes
US TEXT 720 × 400 31.5kHz 70Hz 28.3MHz Yes Yes
*1 Displays a reduced image, except in Dot by Dot. In Dot by Dot, the image will be cut down to panel size then displayed.
*2 Compatible when HDMI MODES is MODE1.
• Depending on the connected computer, images may not be displayed properly even if the compatible signal described above
is input.
