23
E
Menu item details
The menu will differ depending on the input mode.
n
SCREEN
AUTO (D-SUB[RGB])
The CLOCK, PHASE, H-POS, and V-POS are automatically adjusted.
Pressing the ENTER button
performs adjustment. Use this automatic adjustment when you use the D-SUB[RGB] to display a
computer screen for the rst time or when you change the setting of the computer. (See page 32.)
CLOCK (D-SUB[RGB])
Adjusts frequency for sampling clock for applicable video.
Adjust when there is ickering in the form of vertical stripes.
When using the adjustment pattern (see page 32), make adjustments so that no vertical stripe noise appears in it.
PHASE (D-SUB[RGB])
Adjusts sampling clock phase for applicable video. Useful when small characters appear with low contrast and/or there are
ickers at corners. When using the adjustment pattern (see page 32), make adjustments so that no horizontal stripe noise
appears in it.
* Adjustments to PHASE should be made only after CLOCK has been correctly set.
H-POS (D-SUB[RGB])
Adjust the horizontal position of the image.
V-POS (D-SUB[RGB])
Adjust the vertical position of the image.
H-SIZE (D-SUB[RGB])
Adjust the horizontal size of the image.
V-SIZE (D-SUB[RGB])
Adjust the vertical size of the image.
RESOLUTION SETTING (D-SUB[RGB])
H-RESOLUTION
Sets proper horizontal resolution when the resolution of input signals is not recognized properly.
(Adjustment may be impossible with some signals.)
V-RESOLUTION
Sets proper vertical resolution when the resolution of input signals is not recognized properly.
(Adjustment may be impossible with some signals.)
INPUT SIGNAL (D-SUB[RGB])
If a computer connected to the D-SUB[RGB] outputs any of the following resolutions, make a selection from the following
options.
480 LINES .......... AUTO, 640x480 or 848x480
768 LINES ..........AUTO, 1024x768, 1280x768 or 1360x768
1050 LINES ........1400x1050 or 1680x1050
ZOOM2 SPECIAL SETTING (See page 30.)
RESET
Resets the values of the SCREEN menu items to the factory default settings.
Select ON and then press the ENTER button.
