How to Install the Monitor
Mounting precautions
• Sincethemonitorisheavy,consultyourdealerbefore
installing, removing or moving the monitor.
• Wheninstalling,removingormovingthemonitor,ensure
that this is carried out by at least 2 people.
• AstandandmountingbracketcompliantwithVESA
specicationsisrequired.Donotuseanyscrewholesother
than VESA holes for installation.
• Whenmovingthemonitor,besuretoholditwiththe
handles both on the rear and the unit bottom. Do not hold
the LCD panel. This may cause product damage, failure, or
injury.
• Installthemonitorwiththesurfaceperpendiculartoalevel
surface. If necessary, the monitor may be tilted up to 20
degrees.
• Mountingthemonitoronthewallrequiresspecialexpertise
and the work must be performed by an authorized SHARP
dealer. You should never attempt to perform any of this
work yourself. Our company will bear no responsibility
for accidents or injuries caused by improper mounting or
mishandling.
• Thismonitorshouldbeusedatanambienttemperature
between 32°F (0°C) and 104°F (40°C). Provide
enough space around the monitor to prevent heat from
accumulating inside.
For the monitor in horizontal orientation
7-7/8 [20]
Unit: inch [cm]
2 [5]
2
[5]
2
[5]
For the monitor in vertical orientation
Unit: inch [cm]
2 [5]
2
[5]
2
[5]
7-7/8 [20]
*
*
* The monitor can be installed close to a wall, etc.
However,themonitoremitsheatduringoperation.Be
aware that heat emitted from the monitor may discolour
or alter the wall.
• Ifitisdifficulttoprovidethismuchspaceforanyreason
such as the installation of the monitor inside a housing, or
if the ambient temperature may be outside of the range
of 32°F (0°C) to 104°F (40°C), install a fan in the housing
or take other measures to keep the ambient temperature
within the required range.
• Adheretothefollowingwheninstallingthemonitorinthe
vertical orientation. Failing to adhere to the following may
cause malfunctions.
- Install the monitor such that the power LED is located on
the downside.
- Set the MONITOR on the SETUP menu to PORTRAIT.
(See Operation guide.)
• Donotblockanyventilationopenings.Ifthetemperature
inside the monitor rises, this could lead to a malfunction.
• Aftermounting,itisrecommendedtotakesomemeasures
to prevent the monitor from falling down.
• Donotplacethemonitoronadevicewhichgeneratesheat.
• Usethesuppliedverticallogostickerwhenyouinstallthe
monitor in vertical orientation.
*
INPUT
* Donotremovethefactory-afxedstickerbutafxthelogo
stickeroverit.Becarefulnottocovertheremotecontrol
sensor or buttons.
• Besuretouseastandorawall-mount/ceilingbracket
designed or designated for mounting the monitor.
• Thismonitorisdesignedtobeinstalledonaconcretewall/
ceiling or pillar. Reinforced work might be necessary for
some materials such as plaster / thin plastic board / wood
before starting installation.
This monitor and bracket must be installed on a wall which
can endure at least 4 times or more the weight of the
monitor. Install by the most suitable method for the material
and the structure.
