Sharp QT-CD161

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
QT-CD161/141
VARIABLE CAPACITOR
TC1 RTO-H1003SJZZ J AG Trimmer
VIBRATORS
X1 RCRSB0001SJZZ J AN Crystal,4.5 MHz
XL501 RCRM-0003SJZZ J AK Ceramic,4.19 MHz
XL801 RCRM-0002SJZZ J AE Ceramic,16.93 MHz
CAPACITORS
C2 VCTYPA1CU103M J AE 0.01 µF,16V
C3 VCCCPA1HH4R7C J AA 4.7 pF (CH),50V
C4 VCCCPA1HH270J J AA 27 pF (CH),50V
C5,6 VCTYPA1CU103M J AE 0.01 µF,16V
C7 VCKYPA1HB102K J AA 0.001 µF,50V
C8 VCCCPA1HH150J J AA 15 pF (CH),50V
C9 VCCCPA1HH330J J AA 33 pF (CH),50V
C10 VCCUPA1HJ240J J AB 24 pF (UJ),50V
C11 VCCCPA1HH220J J AA 22 pF (CH),50V
C12 VCKYPA1HF223Z J AB 0.022 µF,50V
C13 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C14 VCKYPA1HF223Z J AB 0.022 µF,50V
C16 VCTYPA1CU223M J AB 0.022 µF,16V
C17 VCKYPA1HF473Z J AB 0.047 µF,50V
C18 VCKYPA1HF223Z J AB 0.022 µF,50V
C19 VCCUPA1HJ120J J AA 12 pF (UJ),50V
C20 VCKYPA1HB471K J AA 470 pF,50V
C21 VCKYPA1HF223Z J AB 0.022 µF,50V
C22 VCTYPA1CU103M J AE 0.01 µF,16V
C24 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C25 VCKYPA1HB102K J AA 0.001 µF,50V
C26,27 VCKYPA1HF223Z J AB 0.022 µF,50V
C28 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C29 VCCCPA1HH120J J AA 12 pF (CH),50V
C30 VCCCPA1HH150J J AA 15 pF (CH),50V
C31,32 VCKYPA1HF223Z J AB 0.022 µF,50V
C33 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C34 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C35 VCKYPA1HF223Z J AB 0.022 µF,50V
C36 VCKYPA1HB222K J AA 0.0022 µF,50V
C37 VCKYPA1HF223Z J AB 0.022 µF,50V
C38 VCTYPA1CU183M J AC 0.018 µF,16V
C40 VCKYPA1HB471K J AA 470 pF,50V
C41,42 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C43 VCQSMV1HS152J J AB 0.0015 µF,50V,Styrol
C45,46 VCTYPA1CU223M J AB 0.022 µF,16V
C47~49 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C50 VCKYPA1HF223Z J AB 0.022 µF,50V
C51 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C52 VCKYPA1HF223Z J AB 0.022 µF,50V
C56 VCKYPA1HF103Z J AB 0.01 µF,16V
C57 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C58 VCKYPA1HF103Z J AB 0.01 µF,16V
C59 VCKYPA1HF223Z J AB 0.022 µF,50V
C60 VCKYPA1HB101K J AA 100 pF,50V
C70 VCKYPA1HB102K J AA 0.001 µF,50V
C71 VCKYPA1HF223Z J AB 0.022 µF,50V
C72 VCKYPA1HB102K J AA 0.001 µF,50V
C105,106 VCKYPA1HB182K J AB 0.0018µF,50V
C107,108 VCKYPA1HB821K J AA 820 pF,50V
C109,110 VCKYPA1HB271K J AA 270 pF,50V
C111,112 VCKYPA1HB331K J AA 330 pF,50V
C113,114 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C115,116 VCQYKA1HM183K J AB 0.018 µF,50V,Mylar
C117,118 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C119 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C120 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C121,122 VCKYPA1HF103Z J AB 0.01 µF,16V
C123 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C151,152 VCQYKA1HM393K J AB 0.039 µF,50V,Mylar
C215,216 VCQYKA1HM273K J AB 0.027 µF,50V,Mylar
C217,218 VCKYPA1HB272K J AA 0.0027 µF,50V
C219,220 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
C221,222 VCKYPA1HB102K J AA 0.001 µF,50V
C223,224 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C225 RC-GZA227AF1E J AB 220 µF,25V,Electrolytic
C226 VCKYPA1HF223Z J AB 0.022 µF,50V
C227 RC-GZA478AF1E J 4700 µF,25V,Electrolytic
C228 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C229,230 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
INTEGRATED CIRCUITS
IC1 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC2 VHILA1805//-1 J AM FM/AF IF MPX.,LA1805
IC3 VHITC9216P/-1 J AL PLL,TC9216P
IC101 VHIBA3311L/-1 J AK REC./P.B.Equalizer
Amp.,BA3311L
IC202 VHILA4597//-1 J AH Power Amp.,LA4597
IC203 VHIKIA7808P-1 J AH Voltage Regulator,KIA7808P
IC501 RH-IX0016SJZZ J BC CD/Tuner Control
Microcomputer,IX0016SJ
IC502 VHIPST9142/-1 J AH Reset,PST9142
IC801 VHILA9241M/-1 J AS Servo Amp.,LA9241M
IC802 VHILC78623D-1 J AY Servo/Signal Control,LC78623D
IC803 VHILA6541D/-1 J AW Focus/Tracking/Spin/Slide
Driver,LA6541D
TRANSISTORS
Q1 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q3,4 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q5 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q6 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q9 VSKRA109M//-1 J AC Digital,PNP,KRA109 M
Q201,202 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q251 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q351 VSKTC8050D/-1 J AD Silicon,NPN,KTC8050 D
Q501 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q502 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
DIODES
D1~4 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
D101~103 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
D201 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
D251,252 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
D301,302 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
D303 VHD1N4004//-1 J AB Silicon,1N4004
D501~506 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
! D651~654 VHD1N4004//-1 J AB Silicon,1N4004
D802 VHDDS1SS133-1 J AB Silicon,DS1SS133-1
VD1,2 VHCKV1360NT-1 J AF Variable Capacitance,KV1360NT
VD3 VHCKV1591A2-3 J AU Variable Capacitance,
KV1591A2
ZD1 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD501 VHEDZ5R6BSB-1 J AC Zener,5.6V,DZ5.6BSB
FILTERS
CF1 RFILF0001SJZZ J AD FM IF
CF2 RFILA0002SJZZ J AH AM IF
F1 RFILR0001SJZZ J AD FM Band Pass Filter
TRANSFORMERS
T1 RCILI0001SJZZ J AD FM IF
T2 RCILI0002SJZZ J AD FM Detection
T3 RCILI0003SJZZ J AD AM IF
! T601 RTRNP0001SJZZ J AP Power
COILS
L1 RCILR0004SJZZ J AE FM RF
L2 RCILB0011SJZZ J AF FM,OSC
L3 CCORF0002SJ09 J AM Bar Antenna
L4 RCILB0012SJZZ J AF AM,OSC
L5 VP-CH471K0000 J AB 470 µH,Choke
L301 RCILB0003SJZZ J AD OSC,Bias
L501 VP-CH101K0000 J AB 100 µH,Choke
L801 VP-DHR82K0000 J AE 0.82 µH,Choke
L802 VP-DHR68K0000 J AC 0.68 µH
VARIABLE RESISTORS
VR1 RVR-M0001SJZZ J AC 6.8 kohms (B),Semi-VR [VCO]
VR201 RVR-B0003SJZZ J AK 20 kohms (B),Semi-VR [Volume]
– 1 –
