Sharp QT-CD161 User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
QTCD161/141
C231,232 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C233,234 RC-GZA477AF1A J AC 470 µF,10V,Electrolytic
C252 VCKYPA1HF223Z J AB 0.022 µF,50V
C301 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C302 VCKYPA1HF473Z J AB 0.047 µF,50V
C351 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C352 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C353 VCQYKA1HM562K J AA 0.0056 µF,50V,Mylar
C354 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C501 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C502 VCKYPA1HF223Z J AB 0.022 µF,50V
C503 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C504,505 VCKYPA1HF223Z J AB 0.022 µF,50V
C506 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C508 VCKYPA1HF223Z J AB 0.022 µF,50V
C509 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C510 VCTYPA1CU104M J AB 0.1 µF,16V
C511~513 VCKYPA1HF223Z J AB 0.022 µF,50V
C516 VCKYPA1HB101K J AA 100 pF,50V
C519 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
[QT-CD161 Only]
C520 VCKYPA1HF103Z J AB 0.01 µF,16V
C521 VCKYPA1HB472K J AB 0.0047 µF,50V
C651~654 VCKYPA1HF223Z J AB 0.022 µF,50V
C801 VCKYPA1HF103Z J AB 0.01 µF,16V
C802 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C803 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C804 VCKYPA1HB102K J AA 0.001 µF,50V
C805,806 VCTYPA1CU333M J AB 0.033 µF,16V
C807 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C808 VCTYPA1CU683M J AB 0.068 µF,16V
C809 VCTYPA1CU473M J AB 0.047 µF,16V
C810 VCKYPA1HB181K J AA 180 pF,50V
C811 VCTYPA1CU104M J AB 0.1 µF,16V
C812 VCKYPA1HB331K J AA 330 pF,50V
C813 VCTYPA1CU104M J AB 0.1 µF,16V
C814 VCTYPA1CU103M J AE 0.01 µF,16V
C815 VCKYPA1HB472K J AB 0.0047 µF,50V
C816 VCKYPA1HB102K J AA 0.001 µF,50V
C817 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C818 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C819 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C820 VCKYPA1HB332K J AA 0.0033 µF,50V
C821 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C822 VCKYPA1HB221K J AA 220 pF,50V
C830 VCCCPA1HH2R0C J AA 2 pF (CH),50V
C831 VCKYPA1HB272K J AA 0.0027 µF,50V
C832 VCCCPA1HH270J J AA 27 pF (CH),50V
C833 VCKYPA1HB102K J AA 0.001 µF,50V
C834 VCTYPA1CU333M J AB 0.033 µF,16V
C835 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C837 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C838 VCTYPA1CU103M J AE 0.01 µF,16V
C839 VCTYPA1CU104M J AB 0.1 µF,16V
C840 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C841,842 VCTYPA1CU473M J AB 0.047 µF,16V
C843 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C844 RC-GZA337AF1A J AB 330 µF,10V,Electrolytic
C845 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C846 RC-GZA337AF1A J AB 330 µF,10V,Electrolytic
C847 VCTYPA1CU103M J AE 0.01 µF,16V
C848 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C849 VCKYPA1HF223Z J AB 0.022 µF,50V
C850 VCTYPA1CU104M J AB 0.1 µF,16V
C851 VCKYPA1HF223Z J AB 0.022 µF,50V
C867,868 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C869,870 VCKYPA1HB222K J AA 0.0022 µF,50V
C873 VCKYPA1HF103Z J AB 0.01 µF,16V
C887 VCKYPA1HF223Z J AB 0.022 µF,50V
C888 VCKYPA1HF103Z J AB 0.01 µF,16V
C890 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
RESISTORS
R1 VRD-ST2EE220J J AA 22 ohms,1/4W
R2 VRD-ST2CD104J J AA 100 kohm,1/6W
R3 VRD-ST2CD333J J AA 33 kohms,1/6W
R4 VRD-ST2CD100J J AA 10 ohm,1/6W
R5 VRD-ST2CD103J J AA 10 kohm,1/6W
R6 VRD-ST2CD561J J AA 560 ohms,1/6W
R7 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R8 VRD-ST2CD473J J AA 47 kohms,1/6W
R9 VRD-ST2CD104J J AA 100 kohm,1/6W
R10 VRD-ST2CD683J J AA 68 kohms,1/6W
R11 VRD-ST2CD563J J AA 56 kohms,1/6W
R12 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R13 VRD-ST2CD391J J AA 390 ohms,1/6W
R15 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R16 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R17 VRD-ST2CD103J J AA 10 kohm,1/6W
R18 VRD-ST2CD473J J AA 47 kohms,1/6W
R20 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R24 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R25 VRD-ST2CD333J J AA 33 kohms,1/6W
R29 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R30 VRD-ST2CD153J J AA 15 kohms,1/6W
R35,36 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R37,38 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R39 VRD-ST2CD103J J AA 10 kohm,1/6W
R42 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R43 VRD-ST2CD473J J AA 47 kohms,1/6W
R44 VRD-ST2EE181J J AA 180 ohms,1/4W
R45 VRD-ST2EE221J J AA 220 ohms,1/4W
R46~48 VRD-ST2CD563J J AA 56 kohms,1/6W
R50~52 VRD-ST2CD102J J AA 1 kohm,1/6W
R56 VRD-ST2CD470J J AA 47 ohms,1/6W
R70 VRD-ST2CD223J J AA 22 kohms,1/6W
R71 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R72 VRD-ST2CD102J J AA 1 kohm,1/6W
R101,102 VRD-ST2CD331J J AA 330 ohms,1/6W
R103,104 VRD-ST2CD123J J AA 12 kohms,1/6W
R105,106 VRD-ST2CD153J J AA 15 kohms,1/6W
R107,108 VRD-ST2CD102J J AA 1 kohm,1/6W
R109,110 VRD-ST2CD121J J AA 120 ohms,1/6W
R113,114 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R115~118 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R119,120 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R121,122 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R123,124 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R125 VRD-ST2CD684J J AA 680 kohms,1/6W
R151,152 VRD-ST2CD223J J AA 22 kohms,1/6W
R153,154 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R219,220 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R221,222 VRD-ST2CD102J J AA 1 kohm,1/6W
R223,224 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R225 VRD-ST2CD104J J AA 100 kohm,1/6W
R227,228 VRD-ST2EE121J J AA 120 ohms,1/4W
[QT-CD161 Only]
R230 VRD-ST2EE2R7J J AA 2.7 ohms,1/4W
R251 VRD-ST2CD103J J AA 10 kohm,1/6W
R252 VRD-ST2CD223J J AA 22 kohms,1/6W
R253 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R254 VRD-ST2CD103J J AA 10 kohm,1/6W
R255 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R256 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R351 VRD-ST2EE331J J AA 330 ohms,1/4W
R352 VRD-ST2EE151J J AA 150 ohms,1/4W
R353 VRD-ST2EE473J J AA 47 kohms,1/4W
R354 VRD-ST2EE100J J AA 10 ohm,1/4W
R455,456 VRD-ST2CD153J J AA 15 kohms,1/6W
R457,458 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R501 VRD-ST2EE151J J AA 150 ohms,1/4W
R502 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R503 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R504 VRD-ST2CD104J J AA 100 kohm,1/6W
R505 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R506 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R507 VRD-ST2CD102J J AA 1 kohm,1/6W
R508 VRD-ST2CD563J J AA 56 kohms,1/6W
R509,510 VRD-ST2CD102J J AA 1 kohm,1/6W
R511~513 VRD-ST2CD561J J AA 560 ohms,1/6W
R517,518 VRD-ST2CD103J J AA 10 kohm,1/6W
R519 VRD-ST2CD561J J AA 560 ohms,1/6W
R520~522 VRD-ST2CD102J J AA 1 kohm,1/6W
R523 VRD-ST2CD153J J AA 15 kohms,1/6W
R524 VRD-ST2CD563J J AA 56 kohms,1/6W
R526~528 VRD-ST2CD103J J AA 10 kohm,1/6W
R530,531 VRD-ST2CD153J J AA 15 kohms,1/6W
R532 VRD-ST2CD102J J AA 1 kohm,1/6W [QT-CD161 Only]
R533~541 VRD-ST2CD102J J AA 1 kohm,1/6W
R542 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R543 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R544 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R545 VRD-ST2CD562J J AA 5.6 kohms,1/6W
– 2 –
