PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
QT-CD161/141
R546 VRD-ST2CD153J J AA 15 kohms,1/6W
R547 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R548 VRD-ST2EE470J J AA 47 ohms,1/4W [QT-CD161 Only]
R549,550 VRD-ST2CD153J J AA 15 kohms,1/6W
R552 VRD-ST2CD102J J AA 1 kohm,1/6W
R801 VRD-ST2CD102J J AA 1 kohm,1/6W
R802 VRD-ST2CD104J J AA 100 kohm,1/6W
R803 VRD-ST2CD153J J AA 15 kohms,1/6W
R804 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R805 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R806 VRD-ST2CD101J J AA 100 ohm,1/6W
R807 VRD-ST2CD102J J AA 1 kohm,1/6W
R808 VRD-ST2CD123J J AA 12 kohms,1/6W
R809 VRD-ST2CD273J J AA 27 kohms,1/6W
R810 VRD-ST2CD823J J AA 82 kohms,1/6W
R811 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R812 VRD-ST2CD153J J AA 15 kohms,1/6W
R813 VRD-ST2CD333J J AA 33 kohms,1/6W
R814 VRD-ST2CD103J J AA 10 kohm,1/6W
R815 VRD-ST2CD473J J AA 47 kohms,1/6W
R816 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R817 VRD-ST2CD823J J AA 82 kohms,1/6W
R819 VRD-ST2CD393J J AA 39 kohms,1/6W
R820 VRD-ST2CD103J J AA 10 kohm,1/6W
R821 VRD-ST2CD563J J AA 56 kohms,1/6W
R822 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R823 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R824 VRD-ST2CD103J J AA 10 kohm,1/6W
R825 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R826,827 VRD-ST2CD224J J AA 220 kohms,1/6W
R828~831 VRD-ST2CD102J J AA 1 kohm,1/6W
R832 VRD-ST2CD563J J AA 56 kohms,1/6W
R833 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R834 VRD-ST2CD102J J AA 1 kohm,1/6W
R835 VRD-ST2CD471J J AA 470 ohms,1/6W
R836,837 VRD-ST2CD473J J AA 47 kohms,1/6W
R838 VRD-ST2CD333J J AA 33 kohms,1/6W
R839,840 VRD-ST2CD223J J AA 22 kohms,1/6W
R842 VRD-ST2EE220J J AA 22 ohms,1/4W
R849 VRD-ST2CD104J J AA 100 kohm,1/6W
R856 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R857 VRD-ST2CD273J J AA 27 kohms,1/6W
R858 VRD-ST2CD681J J AA 680 ohms,1/6W
R860 VRD-ST2CD102J J AA 1 kohm,1/6W
R871 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R873,874 VRD-ST2CD101J J AA 100 ohm,1/6W
R875,876 VRD-ST2CD103J J AA 10 kohm,1/6W
R880 VRD-ST2CD101J J AA 100 ohm,1/6W
OTHER CIRCUITRY PARTS
BI801/CNS801 QCNWN0113SJZZ J AF Connector Ass’y,8Pin
BI802/CNS802 QCNWN0114SJZZ J AD Connector Ass’y,5Pin
BI803/CNS803 QCNWN0115SJZZ J AE Connector Ass’y,6Pin
CNP101 QCNCW001DSJZZ J AC Socket,4Pin
CNP201 QCNCW001CSJZZ J AC Socket,3Pin
CNP602 QCNCW002CSJZZ J AD Socket,3Pin
CNS101 ———— –– Connector Ass’y,4Pin
(Not Replacement Item)
CNS201 QCNWN0001SJZZ J AD Connector Ass’y,3Pin
CNS602 QCNWN0132SJZZ J AE Connector Ass’y,3Pin
FW201 QCNWN0133SJZZ J AE Flat Wire,5Pin
FW202 QCNWN0140SJZZ J AE Flat Wire,3Pin [QT-CD161 Only]
FW203 QCNWN0144SJZZ J Flat Wire,8Pin
FW501 QCNWN0134SJZZ J AE Flat Wire,3Pin
FW601 QCNWN0089SJZZ J AG Flat Wire,2Pin
J39 RCORF0001SJZZ J AC Core
J100 RCORF0001SJZZ J AC Core
J201 QJAKM0007AWZZ J AF Jack,Headphones
[QT-CD161 Only]
LCD501 RV-LX0005SJZZ J AU LCD
M601 9GD192112343W J AX Motor with Pulley [Tape]
M701 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
M702 RMOTV0409AFM1 J AN Motor with Gear [Sled]
RX501 VHLN61V380A-1 J AN Remote Sensor
[QT-CD161 Only]
! SO601 QSOCA0001SJZZ J AE AC Socket
SP501,502 VSP0010PBT98S J AL Speaker,Woofer
SW102 QSW-S0001SJZZ J AD Switch,Slide Type
[Record/Playback]
SW201 QSW-S0008SJZZ J AG Switch,Slide Type
[Function/Power]
SW202 QSW-P0001SJZZ J AD Switch,Push Type [X-Bass]
SW501 QSW-K0001SJZZ J AC Switch,Key Type [Tuner Up]
SW502 QSW-K0001SJZZ J AC Switch,Key Type [Tuner Down]
SW503 QSW-K0001SJZZ J AC Switch,Key Type [Band]
SW504 QSW-K0001SJZZ J AC Switch,Key Type [Memory]
SW505 QSW-K0001SJZZ J AC Switch,Key Type [Preset Down]
SW506 QSW-K0001SJZZ J AC Switch,Key Type [Preset Up]
SW507 QSW-F0001SJZZ J AD Switch,Leaf/Skeleton Type
[CD Lid Open/Close]
SW601 9GD192112343W J AX Switch,Push Type [Tape Main]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
W601 QCNWN0101SJZZ J AC Flat,Wire,2Pin
CD MECHANISM PARTS
301 NGERH0586AFZZ J AC Gear,Middle
302 NGERH0587AFZZ J AC Gear,Drive
303 MLEVP1054AFZZ J AC Rail,Guide
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCUSG0613AFZZ J AC Cushion
! 306 RCTRH8179AFZZ J BG Pickup Unit Ass’y
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø4.5×ø1.5×0.25mm
M701 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
M702 RMOTV0409AFM1 J AN Motor with Gear [Sled]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 GCABA1029SJM1 J BC Front Cabinet Ass’y [QT-CD161]
201 GCABA1032SJM1 J BA Front Cabinet Ass’y [QT-CD141]
202 GCABC1029SJSA J AV Top Cabinet [QT-CD161]
202 GCABC1029SJSB J AR Top Cabinet [QT-CD141]
203 GCABB1029SJSA J AZ Rear Cabinet [QT-CD161]
203 GCABB1032SJSA J AV Rear Cabinet [QT-CD141]
204 HPNLC1032SJSA J AS Panel,Control [QT-CD161]
204 HPNLC1036SJSA J AK Panel,Control [QT-CD141]
205 HDECQ0022SJSA J AF Decoration Plate [QT-CD161]
205 HDECQ0022SJSB J AE Decoration Plate [QT-CD141]
206 JKNBK0016SJSA J AE Knob,Volume
207 LHLDW1001SJZZ J AD Nylon Band
208 MSPRC0002SJFD J AC Spring,Battery,+/-
209 JHNDP1001SJSA J AE Handle [QT-CD141]
209 JHNDP1002SJSB J AM Handle [QT-CD161]
210 QANTR0003SJZZ J AL Rod Antenna
211 MSPRZ0001SJFD J AC Spring,Rod Antenna
212 GFTAB1001SJSA J AD Battery Compartment Lid
[QT-CD141]
212 GFTAB1005SJSB J AH Battery Compartment Lid
[QT-CD161]
213 JKNBK0018SJSA J AC Knob,X-BASS
214 LHLDZ1015SJSA J AF Button,Unit [QT-CD161]
214 LHLDZ1015SJSB J AF Button,Unit [QT-CD141]
215 JKNBK0017SJSA J AC Knob,Function [QT-CD161]
215 JKNBK0017SJSB J AC Knob,Function [QT-CD141]
216 GFTAC1001SJSA J AE Cassette Lid [QT-CD141]
216 GFTAC1001SJSD J AM Cassette Lid [QT-CD161]
217 MSPRD0001SJFD J AC Spring,Cassette Lid
218 JBTN-0001SJSA J AC Button,Pause [QT-CD141]
218 JBTN-0007SJSB J AC Button,Pause [QT-CD161]
219 JBTN-0002SJSA J AC Button,Stop [QT-CD141]
219 JBTN-0008SJSB J AC Button,Stop [QT-CD161]
220 JBTN-0003SJSA J AC Button,FF [QT-CD141]
220 JBTN-0009SJSB J AC Button,FF [QT-CD161]
221 JBTN-0004SJSA J AC Button,REW [QT-CD141]
221 JBTN-0010SJSB J AC Button,REW [QT-CD161]
222 JBTN-0005SJSA J AC Button,Play [QT-CD141]
222 JBTN-0011SJSB J AC Button,Play [QT-CD161]
223 JBTN-0006SJSA J AC Button,Rec [QT-CD141]
223 JBTN-0012SJSB J AC Button,Rec [QT-CD161]
224 LANGK0001SJFW J AC Bracket,Button
225 PGUMS0001SJZZ J AB Leg,Cushion
226 GFTAT1001SJSA J AE CD Lid [QT-CD141]
226 GFTAT1001SJSD J AN CD Lid [QT-CD161]
227 CHLDM1001SJ01 J AG Stabilizer Ass’y
227- 1 ———— –– Stabilizer
(Not Replacement Item)
227- 2 PMAGF0002AWZZ J AE Magnet
228 MSPRP0001SJFW J AC Lever,Record
230 MSPRC0001SJFN J AC Spring,Battery,-
– 3 –
