R-231NW
5
NO. PARTS CODE DESCRIPTION Q’TY PRICE RANK
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 FPNLCC029WRKZ Control panel frame with key unit 1
3-1-1 PSHEPB414WREZ Graphic sheet 1
3-1-2 QSW-KA053DRZZ Membrane switch 1 AQ
3-2 JBTN-B308WRFZ Open button 1 AG
3-3 MSPRCA050WRE0 Open button spring 1 AB
3-4 DPWB-A482DRKZ Control unit 1 BH
3-5 QCNC-A023WRZZ Rubber connector 1 AE
3-6 RLCDSA105DRZZ Liquid crystal display 1 AQ
3-7 XEPS730P08XS0 Screw ; 3mm x 8mm 2 AB
3-8 PCUSUA633WREZ Cushion 1 AE
DOOR PARTS
5-1 FDORFA397WRTZ Door panel assembly 1 BB
5-2 GWAKPB262WRRZ Door frame 1 AW
5-3 HPNL-A926WRRZ Door screen 1 AS
5-4 LSTPPA205WRFZ Latch head 1 AF
5-5 MSPRTA187WRE0 Spring 1 AC
5-6 PSHEPA782WREZ Sealer fi lm 1 AG
5-7 GCOVHA424WRFZ Choke cover 1 AK
MISCELLANEOUS
6-5 TINSEB205WRRZ Instruction book 1
6-6 FW-VZC044WREZ Main wire harness 1 AQ
