Sharp SMD2499FS Service Manual

22
SMD2499FS
O TEST MODE (TOUCH KEY CHECK)
TEST PROCEDURES
PROCEDURE
LETTER
COMPONENT TEST
OPERATION (PRESS) DISPLAY
STOP/CLEAR :
TIMER/SETTINGS
POWER LEVEL
POWER LEVEL
START/+30SEC
MORE MENUS (MICROWAVE)
(CLOCK SETTING MODE)
0000000
TOUCH EACH KEY
AFTER EACH KEY IS TOUCHED
VALUES WILL CHANGE AND YOU WILL HEAR A TONE
KEY OK
STOP/CLEAR TO EXIT
:
Touch
within
20 sec.
NOTE:
If you do not
see
"KEY OK" at
the end of
the test, you
may have
missed a key.
Redo the
test and
listen for
each key
tone.
At the end of test and you do not see "KEY OK",
Key Sheet and/or Control Panel may be bad.

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
