Sharp SMD2499FS Service Manual

27
SMD2499FS
may result in severe, possibly fatal, electric shock.
(Example)
High Voltage Capacitor, Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness etc..
WARNING: To Avoid possible exposure to microwave energy, please follow the instructions below
before servicing the oven.
WARNING AGAINST HIGH VOLTAGE:
Microwave ovens contain circuitry capable of producing very high voltage and current. Contact with the following parts
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE
To prevent an electric shock, take the following precautions:
1. Before wiring:
1) Disconnect the power supply cord.
2) Open the drawer.
3) Wait 60 seconds, then discharge the high voltage capacitor.
2. Don’t let the wire leads touch to the following parts:
1) High voltage parts:
Magnetron, High voltage transformer, High voltage capacitor and High voltage rectifier assembly.
2) Hot parts:
Magnetron, High voltage transformer and Oven cavity.
WARNING FOR WIRING
1. Disconnect the power supply cord.
2. Make sure that a definite” click” can be heard when
the microwave oven drawer is unlatched. (Hold the
drawer in a closed position with one hand, then pull
the drawer open, this causes the latch leads to rise, it
is then possible to hear a “click’ as the drawer switches
operate.)
3. Visually check the drawer and cavity face plate for
damage (dents, cracks, signs of arcing etc.).
Carry out any remedial work that is necessary before
operating the oven.
Do not operate the oven if any of the following conditions
exist:
1. Drawer does not close firmly.
2. Drawer latch hook is damaged.
3. The drawer gasket or seal is damaged.
4. The drawer is bent or warped.
5. There are defective parts in the drawer interlock
system.
6. There are de fective parts in the microwave generating
and transmission assembly.
7. There is visible damage to the oven.
Do not operate the oven:
1. Without the RF gasket (Magnetron).
2. If the wave guide or oven cavity are not intact.
3. If the drawer is not closed.

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
