Sharp SMD2499FS Service Manual

43
SMD2499FS
PARTS LIST
ELECTRICAL PARTS
1-1 RC-QZA411WRZZ HV CAPACITOR 1 AN
1-2 RH-DXA014WRZZ H.V RECTIFIER 1 AF
1-3 DPWB-B696DRKZ PSU UNIT 1 BF
1-4 RTRN-A861WRZZ HV TRANSFORMER 1 BF
1-5 FMOTDA119WRKZ TT MOTOR ASSY 1 AR
1-6 FANGTB020MRK2 AUTO DRAWER GEAR ASSY 1 BG
1-7 FHLD-A033WRKZ LED HOLDER ASSY 2 AG
1-8 RV-MZA427WRZZ MAGNETRON 1 BM
1-9 FMOTEA629WRKZ FAN MOTOR ASSY 1 BG
1-10 PHOK-A178WRFZ LATCH HOOK R ASSY 1 AG
1-11 RTHM-A148WRZZ THERMAL CUT OUT 2 AF
1-12 FDTCTA272WRKZ SENSOR ASSY 1 AP
1-13 PHOK-A174WRFZ LATCH HOOK L ASSY 1 AG
1-14 FPWBFA555WRKZ NOISE FILTER UNIT 1 AQ
1-15 QFS-BA009WRE0 FUSE 20A 1 AF
1-16 FMOTEA631WREZ FAN MOTOR 1 BD
1-17 FH-HZA140WREZ THERMISTOR 2 AL
1-18 QSW-MA168WRZZ INTERLOCK SWITCH A 3 AE
1-19 LHLD-A420WRFZ SENSOR HOLDER 1 AF
1-20 FACCDA129WREZ POWER SUPPLY CORD 1 AQ
1-21 DPWB-B383DRKZ1 POWER UNIT 1 BA
1-22 RRLYDA060DRZZ RELAY 2 AU
1-23 QSW-MA183WRZZ INTERLOCK SWITCH 1 AH
1-24 QSW-MA169WRZZ MONITOR SWITCH 1 AD
1-25 FPWB-B434DRKZ WIRELESS ADAPTER 1 AY
1-26 RMOTEA547WRZZ CONVECTION MOTOR 1 AW
1-27 RMOTEA557WRZZ CYCLE MOTOR 1 AY
1-28 RTHM-A147WRZZ THERMAL CUTOUT 1 AF
1-29 RSNSZA003DRZZ SENSOR MODULE UNIT 1 AX
1-30 FDUC-A659WRKZ REAR CONVECTION ASSY 1 BL
1-31 RMOTDA248WRZZ TURNTABLE MOTOR 3 AH
1-32 FDUC-A663WRKZ TOP CONVECTION ASSY 1 BQ
1-33 RHET-A516WRZZ GRILL HEATER 3 AX
1-34 FW-VZA451DRZZ WIFI HARNESS 1 AK
1-35 FW-VZA453DRZZ SENSOR HARNESS 1 AG
1-36 FW-VZA458DRZZ LED HARNESS 1 AC
1-37 FW-VZC655WREZ MAIN HARNESS 1 BE
1-38 FW-VZC656WREZ CONTROL HARNESS 1 AX
1-39 FW-VZC657WREZ CPU HARNESS 1 AQ
1-40 FW-VZC658WREZ MOTOR HARNESS 1 AH
1-41 FW-VZC660WREZ TTM HARNESS 1 AE
1-42 RTHM-A146WRZZ THERMAL CUTOUT 2 AH
1-43 RTHM-A157WRZZ SH THERMOSTAT 1 AM
CABINET PARTS
2-1 FCABUB006WRYZ TOP OUTER CASE 1 AZ
2-2 LANGQA830WRPZ AC CORD MOUNT ANGLE 1 AM
2-3 LBSHCA014WRE0 CORD BUSHING 1 AB
2-4 FCABDA065WRYZ REAR OUTER CASE 1 AA
2-5 GDAI-A567WRWZ BOTTOM PLATE 1 AZ
2-6 GCABUB421WRWZ LEFT OUTER CASE 1 AW
2-7 PCOVPA670WRPZ LATCH COVER 2 AB
2-8 JHNDPA540WRFZ CARRY HANDLE 4 AF
2-9 GCOVPA083WRWZ CABINET COVER 1 AE
2-10 GCABUB423WRWZ RIGHT OUTER CASE 1 AW
2-11 LANGTB439MRT0 SIDE ANGLE RIGHT 1 AM
2-12 LANGTB438MRT0 SIDE ANGLE LEFT 1 AM
2-13 LANGTB440MRP0 C/P REAR ENCLOSURE 1 AH
CONTROL PANEL PARTS
3-1 CPNLCC042MRK0 CONTROL PANEL ASSY 1 BV
3-2 DPWBFB308MRU0 DRAWER DISPLAY UNIT 1 BC
3-3 XEBS730P08XS0 SCREW 2 AA
REF. NO. PART NO. DESCRIPTION Q'TY CODE

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
