Sharp SMD2499FS Service Manual

44
SMD2499FS
REF. NO. PART NO. DESCRIPTION Q'TY CODE
OVEN PARTS
4-1 DOVN-A865WRKZ OVEN ASSY 1 N/A
4-2 PPAC-A224WREZ INTAKE DAMPER PACKING 1 AG
4-3 PPAC-A225WREZ EXHAUST DAMPER PACKING 1 AF
4-4 LANGTA622WRWZ DRIVE GEAR MOUNT AG 1 AP
4-5 GCOVPA087WRWZ FP-OC ENCLOSE COVER 1 AQ
4-6 LANG-A159WRWZ REAR SEPARATE AG 1 AF
4-7 LANGQA956WRWZ BLOWER MOTOR TO-AG 1 AS
4-8 LANGQA960WRPZ MG THERMO TO AG 1 AE
4-9 LANGQA975WRWZ MG REFLECTOR 1 AE
4-10 LANGTA614WRTZ DOOR SUPPORT AG-L 1 AT
4-11 LANGTA616WRTZ DOOR SUPPORT AG-R 1 AT
4-12 LANGTA617WRTZ DOOR SUPPORT BOTTOM 1 AU
4-13 LANGTA619WRWZ CHASSIS SUPPORT-L 1 AP
4-14 LANGTA621WRWZ CHASSIS SUPPORT-R 1 AP
4-15 LANGTA636WRWZ MG FAN MOUNT AG 1 AN
4-16 LANGTA642WRWZ LED AIR GUIDE 1 AK
4-17 LBNDKA207WRWZ HVC BAND 1 AG
4-18 MSLIFA007WREZ SLIDE RAIL L 1 AZ
4-19 MSLIFA008WREZ SLIDE RAIL R 1 AZ
4-20 MSLIFA013WREZ SLIDE RAIL 1 AT
4-21 NGERRA001WRFZ RACK GEAR 1 AL
4-22 PCLICA044WREZ CANOE CLIP 2 AV
4-23 PDUC-B442WRWZ BLOWER FAN DUCT 1 AT
4-24 PDUC-B450WRFZ EXHAUST DUCT LOWER 1 AQ
4-25 PDUC-B462WRFZ INTAKE DUCT LOWER 1 AM
4-26 PGIDHA081WRWZ R-REAR AIR GUIDE-B 1 AG
4-27 PGIDHA083WRWZ R-REAR AIR GUIDE-U 1 AH
4-28 PGIDHA085WRWZ L-REAR AIR GUIDE-B 1 AF
4-29 PGIDHA087WRWZ L-REAR AIR GUIDE-U 1 AH
4-30 PHOK-B032MRE0 PUSH LATCH 1 AK
4-31 LANGTA628WRWZ SLIDE MOUNT AG BOTTOM 1 AP
4-32 PCOVQA049WRWZ HEAT COVER UPPER 1 AW
4-33 PFPF-A375WREZ TOP CONV INSULATION 1 AP
4-34 LHLDWA010WRE0 PURSE LOCK S 1 AA
4-35 LHLDWA073WREZ PURSE LOCK L 4 AA
4-36 PDUC-B444WRWZ EXHAUST DUCT M 1 AH
4-37 PDUC-B460WRFZ INTAKE JOINT DUCT 1 AQ
4-38 PFPF-A369WREZ HEAT INSULATION UPPER 1 AV
4-39 PFPF-A373WREZ HEAT INSULATION SIDE 2 AD
4-40 LHLD-A417WRFZ PSU HOLDER 1 AN
4-41 TLAB-B139MRR0 MICROWAVE MENU LABEL 1 AE
4-42 LANGQA972WRWZ LAMP GLASS COVER 2 AF
4-43 PGLSPB103WREZ LAMP GLASS 2 AD
4-44 PPAC-A223WREZ LAMP GLASS PACKING 2 AC
4-45 PGISHA078WREZ HEATER SUPPORT 3 AD
4-46 MSPRCA184WREZ THERMISTOR SPRING 2 AD
4-47 LHLDWA075WREZ WIRE HOLDER 6 AA
CUSHIONS
5-1 PCUS-A428WREZ CUSHION-A 2 AB
5-2 PCUS-A429WREZ CUSHION-B 1 AB
5-3 PCUS-A430WREZ CUSHION-C 1 AB
5-4 PCUS-A431WREZ CUSHION-D 2 AB
5-5 PCUS-A432WREZ CUSHION-E 1 AB
5-6 PCUS-A433WREZ CUSHION-F 4 AB
5-7 PCUS-A434WREZ CUSHION-G 1 AB
5-8 PCUS-A436WREZ CUSHION-I 1 AB
5-9 PCUS-A437WREZ CUSHION-J 1 AB
5-10 PCUS-A438WREZ CUSHION-K 1 AB
5-11 PCUS-A452WREZ CUSHION-L 1 AB
5-12 PCUS-A453WREZ CUSHION-M 2 AB
5-13 PCUS-A454WREZ CUSHION-N 2 AB

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
