Sharp SMD2499FS Service Manual

45
SMD2499FS
REF. NO. PART NO. DESCRIPTION Q'TY CODE
DOOR
6-1 DDORFB793WRKZ DOOR ASSY 1 BG
6-2 PPACGA302WREZ DRAWER PACKING 2 AD
6-3 LHLD-A419WRFZ RACK STAY HOLDER 8 AC
6-4 LSTPPB072MRF0 LATCH HEAD R 1 AD
6-5 LSTPPB073MRF0 LATCH HEAD L 1 AD
6-6 LSTYPA008WRFZ RACK STAY 8 AD
6-7 LX-HZB001MRE0 SPECIAL SCREW 2 AB
6-8 MSPRTB035MRE0 LATCH SPRING 2 AA
6-9 PPACGA300WRFZ HOLE COVER 4 AC
6-10 FCOV-B601MRK0 DOOR FRAME ASSY 1 BS
6-11 FCOVHB011MRK0 CHOKE COVER ASSY 1 BB
6-12 GCOVHB090MRF0 DOOR SUPPORT COVER 1 AE
6-13 TCAUAB059MRR0 CONSUMER WARNING LABEL 1 AB
MISCELLANEOUS
7-1 CFZK-C073WRKZ ACCESSORY ASSY 1 BL
7-2 PGLSPB105WREZ COOKING TRAY 1 BA
7-3 UAMI-A193WREZ RACK-L 1 AV
7-4 UAMI-A194WREZ RACK-U 1 AV
7-5 TINSEB579MRR0 OPERATION MANUAL 1 AK
7-6 TINSEB580MRR0 INSTALLATION INSTRUCTIONS 1 AD
7-7 TLAB-B143MRR0 CONV MENU LABEL 1 AE
7-8 TMAPCA855WRRZ SCHEMATIC DIAGRAM 1 AB
7-9 TCAUAB050MRR0 MONITOR CAUTION 2 AD
7-10 TCAUAA387WRRZ DHHS GRD CAUTION 1 AD
7-11 TCAUHA412WRRZ USER CAUTION LABEL 1 AA
7-12 LX-CZB073MRE0 SCREWS 4 AA
SCREWS, NUTS, AND WASHERS
8-1 XOTS740P08000 SCREW 125 AA
8-2 XOTS740P12RV0 SCREW 7 AB
8-3 XOTWW40P06000 SCREW 11 AB
8-4 XOTWW40P08000 SCREW 19 AA
8-5 XOTWW40P12000 SCREW 4 AA
8-6 XEBS730P08000 SCREW 12 AA
8-7 XETS740P08000 SCREW 2 AA
8-8 XETS740P10000 SCREW 14 AA
8-9 XCPS730P14000 SCREW 2 AB
8-10 XCTS740P14000 SCREW 4 AC
8-11 XBTWW50P08000 SCREW 3 AG
8-12 XBTS740P08RV0 SCREW 1 AA
8-13 XHPS730P06000 SCREW 9 AA
8-14 XHPS740P06000 SCREW 7 AA
8-15 XHPS740P08000 SCREW 10 AA
8-16 XHPS740P08K00 SCREW 8 AB
8-17 XEPS740P10000 SCREW 1 AA
8-18 XHTS730P08000 SCREW 1 AA
8-19 XHTS740P12000 SCREW 4 AA
8-20 XHTS740P08RV0 SCREW 1 AA
8-21 XHTWW40P06000 SCREW 4 AF
8-22 XNEUW50-40000 SCREW 1 AP
8-23 XNES740-32000 SCREW 17 AB
8-24 XWHUW50-08000 SCREW 1 AA
8-25 XWSUW50-13000 SCREW 1 AF
8-26 XWSUW40-10000 SCREW 1 AA
8-27 XWHUW48-15120 SCREW 2 AA
8-28 LX-BZA143WREZ SCREW 4 AD
8-29 LX-BZA144WREZ SCREW 10 AD
8-30 LX-BZA148WREZ SCREW 61 AD
8-31 LX-BZA153WREZ SCREW 8 AB
8-32 LX-BZA163WREZ SCREW 3 AF
8-33 LX-BZA164WREZ SCREW 2 AK
8-34 LX-BZA217WREZ SCREW 2 AB
8-35 LX-CZ0052WRE0 SCREW 2 AE
8-36 LX-CZA084WREZ SCREW 3 AA
8-37 LX-NZA002WRE0 SCREW 1 AN
8-38 LX-NZB006MRE0 SCREW 2 AA
8-39 LX-HZB001MRE0 SCREW 2 AB
8-40 XOTWW40P08XU0 SCREW 2 AA
8-41 XCTWW40P12000 SCREW 3 AA

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
