Sharp SMD2499FS Service Manual

6
SMD2499FS
ITEM DESCRIPTION
Power Requirements 120 Volts (USA)
14.2 Amperes (Microwave) / 13.0 Amperes (Convection)
60 Hertz / Single phase, 3 wire grounded
Microwave Power Output 900 watts (IEC 705 Test Procedure)
Operating frequency of 2450MHz
Power Consumption Microwave - 1700 W Convection - 1560 W
Convection Power Output 1450 Watts
Case Dimensions Width 23 12/32" Height 19 20/32" Depth 22 8/32"
Cooking Cavity Dimensions
(1.4 Cubic Feet ) Width 16 30/32" Height 8 24/32" Depth 16 22/32"
Control Complement Touch Control System
Timer (0 - 99 min. 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI ........................................... Full power throughout the cooking time
P-90 .............................................................. approx. 90% of Full Power
P-80 .............................................................. approx. 80% of Full Power
P-70 .............................................................. approx. 70% of Full Power
P-60 .............................................................. approx. 60% of Full Power
P-50 .............................................................. approx. 50% of Full Power
P-40 ............................................................... approx. 40% of Full Power
P-30 .............................................................. approx. 30% of Full Power
P-20 .............................................................. approx. 20% of Full Power
P-10 ............................................................... approx. 10% of Full Power
P-0 .............................................. No power throughout the cooking time
Convection Operation
TOP CONVECTION ................................... 1000 W
GRILL CONVECTION.... ............................ 500 W x 3 - TTL 1500 W
REAR... ....................................................... 1500 W
Convection:
Bake/Warm, Roast, Grill/Toast, More Menus, Speed Cook, Air Fry
Microwave:
Popcorn, Reheat, Cook, More Menus, Defrost, Open/Close, Stop/Clear,
Start/+30 sec, Power Level, Timer/Settings, Number Keys with Convection
Temp settings.
Oven Cavity Light LED x 2
Remote Start Wi-Fi connect by way of "Sharp Kitchen" App.
Weight 128 lbs
Safety Standard UL Listed FCC Authorized
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J
CONVECTION MICROWAVE DRAWER SPECIFICATION

Sharp SMD2499FS Specifications

General

Style	drawer
Color	stainless steel
Total Capacity	1.4 cu. ft.
Convection	yes
Power Levels	11
Sensor Cooking	yes
Quick Start	yes
Timer	yes
Wi-Fi	yes
Remote Control	yes
Max Power Consumption	900 watts
Microwave Power	900 watts
Voltage	115 volts
Current	15

Weight and Dimensions

Depth	20-7/8"; 27"; 20 7/8 inch; 23-1/2"; 16-7/16"
Height	19 1/2 inch; 19-3/4"; 8-3/4"; 19-1/2"; 24-1/2"; 19-3/8"
Width	23-5/8"; 27-1/2"; 22-3/8"; 23 5/8 inch; 23-7/8"; 16-15/16"
