2. PART NAMES AND FUNCTION
For details on the use of each control.
Front view
When the cassette compartment door is open
Terminal cover
Microphone
Zoom lens
Speaker
VIDEO jack
DC IN jack
Shoulder strap loop
Lithium battery holder
Cassette holder
Lens hood
Cassette compartment door release
Cassette compartment door
AUDIO jack
Rear view
Bottom view
Battery compartment door
Power Zoom Wide angle/ Telephoto control VOLume control
DISPLAY button
Operation buttons
CHARGE indicator
Remote Sensor (VL-AH151S/H/E only)
MENU button
LCD monitor screen
RECord START/STOP button
Shoulder strap loop FADE button Hand strap
Tripod socket
Battery compartment door release
Power switch (CAMERA/VCR select switch)
