Guide roller assembly
Tu pole base assembly
Guide rail
Tu loading arm assembly
Tu pressure spring
Tu loading gear
S loading gear
S pressure spring
S loading arm assembly
S pole base assembly
G
G
F
F
Item
Tightening torque
Quantity
F CWø0.7-ø2.2-t0.25 2
G Special screw · 5mN·m 2
M1.2 x L1.8
(Tentative tightening)
8.
9.
(3) Loading motor
assembly
Grease
(Rear surface,
groove side
surface)
399
453
461
H
A
A
A
A
(2) PB guide spring
Grease
(Front surface, rear surface,
groove side surface)
(1) Drum base sub assembly
Item
Tightening torque
Quantity
A S Tight · M1.4 x L3 70mN·m 4
H
Special screw with step
· 70mN·m 1
M1.4 x L6.25
378
363
325
SL chassis holder S
Solder-joint
Positioning
(2) Down switch
attachment
angle sub
assembly
Positioning
Fit, clamping the plate
(1) AHC assembly
Item
Tightening torque
Quantity
A S Tight · M1.4 x L3 70mN·m 1
P S Tight · M1.4 x L4 70mN·m 1
8-5-2. Reassembly in side of the Slide chassis.
Note) Numbers before part names are given as a guide to the order of assembly.
As for greasing/oiling/cleaning places refer to the attached drawings (Grease/Oil application Fig. 3, 4).
Grease
375
330
337
376
456
457
391
391
353
374
(9) J ( 411 ~ 415 )
Fit the main brake SPR from
above, and close with the hook.
(1) Slide chassis assembly
with sensor FPC
Sensor FPC guide
(2) Brake shifter
Ass'y
(3) S main
brake
(3) I
(4) Main brake
SPR.
(5) Tu main
brake
(5) I
(6) Main brake
SPR.
(7) S cassette
stay
(7) B
(8) S reel base Ass'y
(8) J ( 411 ~ 415)
(9) Tu reel base Ass'y
8-5
Item
Tightening torque
Quantity
B S Tight · M1.4 x L2 40mN·m 1
I CWø0.7-ø1.8-t0.1 2
J Wø1.2-ø2.5-t0.3 2
(3) Dew FPC cover
P
A
Grease
To Next Page
