References
Specifications
As part of our policy of continuous improvement, SHARP reserves the right to
make design and specification changes for product improvement without prior
notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individ-
ual units.
General
Speaker section
Radio
Tape recorder
Power source AC 110-127/220-240 V, 50/60 Hz
DC IN 12V
DC 15 V , (UM/SUM-1 or R20) x 10
Power consumption 30 W
Output power PMPO: 400 W (Total) (AC operation)
MPO: 36 W (18 W + 18 W) (AC operation,
10% T.H.D)
RMS: 25 W (12.5 W + 12.5 W) (AC operation,
10% T.H.D)
Output terminal Headphones: 16 - 50 ohms (recommended: 32
ohms)
Input terminals Mixing microphone : 600 ohms
Line input: 350 mV/47 kohms
Dimensions Width: 300 mm (11-4/5")
Height: 246 mm (9-2/3")
Depth: 260 mm (10-1/4")
Weight 3.75 kg (8.27 lbs.) without batteries
Type 2-way type
Speakers 13 cm (5-1/8") Woofer
5 cm (2") Tweeter
Maximum input power 25 W
Rated input power 12.5 W
Impedance 8 ohms
Dimensions Width: 232 mm (9-1/8")
Height: 262 mm (10-5/16")
Depth: 235 mm (9-1/4")
Weight 1.80 kg (3.97 lbs.)/each
...
Frequency range FM: 88 - 108 MHz
SW1: 3.2 - 7.3 MHz
SW2: 9.5 - 21.85 MHz
MW: 531 - 1,602.0 kHz
Frequency response 60 - 8,000 Hz (Normal tape)
Signal/noise ratio 40 dB
Wow and flutter 0.3% (WRMS)
Motor DC 12 V electric governor
Bias system AC bias
Erase system Magnet erase
