Sharp XG-C55X Service Manual

170
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
XG-C55X
DUNTKB929FE01
OUTPUT UNIT(Continued)
R4543 VRS-CY1JF911JY J 910 1/16W Metal Oxide AB
R4544 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R4545 VRS-CY1JF182FY J 1.8k 1/16W Metal Oxide AA
R4546 VRS-CY1JF221FY J 220 1/16W Metal Oxide AA
R4547 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4548 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R4549 VRS-CY1JF183JY J 18k 1/16W Metal Oxide AA
R4550 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4551 VRS-TV1JD000JY J 0 1/16W Metal Oxide AA
R4553 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4555 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4556 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R4557 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R4558 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R4559 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R4560 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4561 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R4562 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R4563 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4564 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R4565 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R4566 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R4567 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4568 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4569 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4570 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4571 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R4572 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R4573 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4574 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4575 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4576 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4577 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R4578 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4580 VRS-CY1JF394JY J 390k 1/16W Metal Oxide AA
R4581 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4585 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R4586 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R4587 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R4589 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4590 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R4592 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R4593 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R4594 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7001 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7002 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R7004 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R7005 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R7009 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R7010 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R7011 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7012 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R7013 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R7014 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R7015 VRS-CY1JF152FY J 1.5k 1/16W Metal Oxide AA
R7016 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7023 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7025 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7026 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7027 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7028 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R7029 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7030 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7031 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7033 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R7034 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7040 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7041 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R7050 VRN-CY1JF103DY J 10k 1/16W Metal Film AA
R7054 VRN-CY1JF103DY J 10k 1/16W Metal Film AA
R7058 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7059 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7061 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7062 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R7063 VRS-CJ1JF100JY J 10 1/16W Metal Oxide AA
R7064 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7065 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7066 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7067 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7068 VRS-CJ1JF100JY J 10 1/16W Metal Oxide AA
R7069 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R7070 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R7078 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7083 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R7084 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7090 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
SWITCH
S2601 QSW-K0108CEZZY J Switch AD
MISCELLANEOUS PARTS
FB301 RBLN-0064TAZZY J Ferrite Bead AB
FB302 RBLN-0064TAZZY J Ferrite Bead AB
FB1102 RBLN-0062TAZZY J Ferrite Bead AB
FB1202 RBLN-0062TAZZY J Ferrite Bead AB
FB1302 RBLN-0062TAZZY J Ferrite Bead AB
FB1401 RBLN-0062TAZZY J Ferrite Bead AB
FB1402 RBLN-0062TAZZY J Ferrite Bead AB
FB2401 RBLN-0059CEZZY J Ferrite Bead AB
FB2751 RBLN-0062CEZZY J Ferrite Bead AC
FB2753 RBLN-0059CEZZY J Ferrite Bead AB
FB4503 RBLN-0061TAZZY J Ferrite Bead AD
FB7001 RBLN-0065TAZZY J Ferrite Bead AA
FB7002 RBLN-0065TAZZY J Ferrite Bead AA
FB7003 RBLN-0065TAZZY J Ferrite Bead AA
FB7004 RBLN-0065TAZZY J Ferrite Bead AA
FB7005 RBLN-0059CEZZY J Ferrite Bead AB
FB7006 RBLN-0059CEZZY J Ferrite Bead AB
P301 QPLGN0474TAZZY J Plug, 4pin(SO1) AD
P1302 QPLGN0463TAZZY J Plug, 4pin(TP) AC
P2602 QPLGN0363TAZZY J Plug, 3pin(RC) AC
P2751 QPLGN1174TAZZY J Plug, 11pin(EB1) AE
P2752 QPLGN0364TAZZY J Plug, 3pin(FD) AC
P3102 QCNCM3021TAZZ J Connector, 30pin(1A) AL
P3602 QCNCM2021TAZZ J Connector, 20pin(1B) AH
P7001 QPLGNA008WJZZ J Plug, 24pin(EA) AD
P7002 QPLGN0264TAZZY J Plug, 2pin(L1) AC
P7004 QPLGN0264TAZZY J Plug, 2pin(L3) AC
P7005 QLUGHA002WJZZ J Lug AB
P7006 QPLGN0264TAZZY J Plug, 2pin(L2) AC
P8001 QCNCMA019WJZZY J Connector, 82pin(PC0) AH
P8002 QCNCMA019WJZZY J Connector, 82pin(PC1) AH
SC1101 QSOCN3071TAZZY J Socket, 30pin(RP) AE
SC1201 QSOCN3071TAZZY J Socket, 30pin(GP) AE
SC1301 QSOCN3071TAZZY J Socket, 30pin(BP) AE
SC2601 QSOCN1897REZZY J Socket, 18pin(KY) AE
GCOVHA014WJKZ J Cover AD
PSLDHA015WJFW J AE
PSLDHA016WJFW J AE
