Sharp XG-C55X Service Manual

178
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
XG-C55X
CPCi-A002CE30
PC I/F UNIT(Continued)
SWITCH
SW80019DK001-70012 J Slide Switch, SSSS811101 AL
MISCELLANEOUS PARTS
FB8006 9DK001-81062 J Ferrite Bead, BLM21P221SG AE
FB8013 9DK001-81062 J Ferrite Bead, BLM21P221SG AE
FB8015 9DK001-81062 J Ferrite Bead, BLM21P221SG AE
SC8001 9DK001-60078 J Connector, 82pin AQ
SC8002 9DK001-60078 J Connector, 82pin AQ
CASE8001 PSLDMA008WJFW J Shield Case AK
HOLD8001 LHLDW1021GE00 J Wire Holde AB
SHEET8001 PSPAZA061WJZZ J Sheet AD
SHEET8002 PSPAZA061WJZZ J Sheet AD
SHEET8003 PSPAGA134WJZZ J Sheet
SHEET8004 PSPAGA134WJZZ J Sheet
LABEL8001 9DK001-97078 J Serial No. Label AD
NSFTZA001WJFW J Shaft, x2 AD
CABINET AND MECHANICAL PARTS
1 Not Available – Rear Body Unit Ass'y —
1-1 DBDYRA005WJ01 J Rear Body Ass'y AY
1-1-1 Not Available – Rear Body —
1-1-2 HiNDPA506WJSA J Terminal Indication Panel AH
1-1-3 HiNDPA085WJZZ J Earth Label AD
1-1-4 HiNDPA516WJZZ J Lamp Replacement Label AE
1-1-5 PSPAKA008WJ00 J Spacer, x2 AD
1-2 LX-HZ3106CEFD J Screw, x1 AB
1-3 LX-NZ3173CEFW J Insert Nut, x1 AD
2 Not Available –Top Body Unit Ass'y —
2-1 DBDYTA036WJ01 J Top Body Ass'y BG
2-1-1 Not Available –Top Body —
2-1-2 GCOVAA032WJKA J LED Cover, X2 BB
2-1-3 Not Available – "SHARP" Badge —
2-1-4 HiNDPA057WJSA J "IQ" Label AF
2-1-5 DBTN-A013WJ01 J Operation Button Ass'y AX
2-1-5-1 Not Available – Operation Button —
2-1-5-2 HDECQA025WJKA J Decoration Button-A AH
2-1-5-3 HDECQA026WJKA J Decoration Button-B AH
2-1-5-4 HDECQA027WJKA J Decoration Button-C AH
2-1-7 PSPAZA106WJZZ J Spacer, x4 AA
2-2 JBTN-A014WJKA J Height Adjust Button AE
2-3 LANGKA006WJFW J Fixing Angle AD
2-4 MSPRCA001WJFW J Spring, for Height AB
Adjust Button
2-5 PSPAT0013CEZZ J Tape, x4 AC
2-6 QCNW-A492WJZZ J Leaf Switch AH
2-7 XBPSF26P06000 J Screw, x1 AA
2-8 XEBSD30P08000 J Screw, x1 AA
2-9 XEPSD26P08000 J Screw, x1 AA
3
Not Available – Bottom Body Unit Ass'y —
3-1 DBDYUA003WJ12 J Bottom Body Ass'y BC
3-1-1 Not Available – Bottom Body —
3-1-2 HiNDPA505WJSA J Model Label AL
3-1-3 HiNDPA292WJSA J FCC Label AL
3-1-4 HiNDPA114WJSB J Hot Caution Label AD
3-1-5 Not Available – Kensington Standard —
Security Connector
3-1-6 LX-NZ3120CEFW J Insert Nut(R) AB
3-1-7 LX-NZ3122CEFW J Insert Nut(L) AC
3-1-8 PFiLDA003WJZZ J PBS Filter AG
3-2 DCOVAA029WJ01 J Bottom Filter Cover Ass'y AR
3-2-1 Not Available – Bottom Filter Cover —
3-2-2 HPNC-A002WJSA J Intake Punching Cover AL
3-3 GCOVA1824CESA J R/C Cover AD
3-4 GCOVAA030WJKA J Exhaust Panel AM
3-5 GCOVAA038WJKA J Handle Cover, x2 AF
3-6 GLEGPA003WJKA J Adjuster Foot(Front) AW
3-7 GLEGPA004WJKA J Adjuster Foot(Rear, Right) AH
3-8 GLEGPA005WJKA J Adjuster Foot(Rear, Left) AH
3-9 HPNC-A001WJSA J Punching Cover AL
3-10 JHNDAA003WJZZ J Carrying Handle BA
3-11 LANGKA040WJFW J Anti-Theft Angle AD
3-12 LX-HZ3105CEFD J Screw, for Insert Nut, x1 AB
3-13 LX-NZ3095CEFD J Nut Screw(R) AA
3-14 LX-NZ3123CEFE J Nut Screw(L) AD
3-15 LX-NZ3173CEFW J Insert Nut, x1 AD
3-16 LX-NZA003WJFW J Nut, x3 AD
3-17 PFiLDA002WJZZ J Filter AE
3-18 PSLDMA074WJZZ J Shield AK
3-19 PSPAH0648CE00 J Spacer, x2 AB
3-20 PSPAT0013CEZZ J Tape, x2 AC
3-21 PZETKA013WJZZ J Shield Spacer, x1 AG
3-22 PZETKA014WJZZ J Shield Spacer, x1 AH
3-23 PZETKA015WJZZ J Shield Spacer, x1 AD
3-24 QCNW-A493WJZZ J Leaf Switch AF
3-25 XBPSD30P08JS0 J Screw, x8 AA
3-26 XBPSD40P05J00 J Screw, x3 AA
