Sharp XG-C55X Service Manual

177
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
XG-C55X
CPCi-A002CE30
PC I/F UNIT(Continued)
C8668 9DK001-42157 J 0.1 25V Ceramic AC
C8670 9DK001-42157 J 0.1 25V Ceramic AC
C8672 9DK001-42157 J 0.1 25V Ceramic AC
C8678 9DK001-42157 J 0.1 25V Ceramic AC
C8682 9DK001-42157 J 0.1 25V Ceramic AC
C8685 9DK001-42157 J 0.1 25V Ceramic AC
C8686 9DK001-42157 J 0.1 25V Ceramic AC
C8687 9DK001-42157 J 0.1 25V Ceramic AC
C8688 9DK001-42157 J 0.1 25V Ceramic AC
C8689 9DK001-42157 J 0.1 25V Ceramic AC
C8697 9DK001-42157 J 0.1 25V Ceramic AC
C8708 9DK001-40090 J 47 4V Electrolytic AF
C8759 9DK001-42157 J 0.1 25V Ceramic AC
C8901 9DK001-42157 J 0.1 25V Ceramic AC
C8902 9DK001-42156 J 1 10V Ceramic AC
C8904 9DK001-42157 J 0.1 25V Ceramic AC
C8905 9DK001-42157 J 0.1 25V Ceramic AC
C8906 9DK001-42157 J 0.1 25V Ceramic AC
C8909 9DK001-42156 J 1 10V Ceramic AC
C8910 9DK001-42157 J 0.1 25V Ceramic AC
C8911 9DK001-42156 J 1 10V Ceramic AC
C8912 9DK001-42156 J 1 10V Ceramic AC
C8913 9DK001-42156 J 1 10V Ceramic AC
C8914 9DK001-42156 J 1 10V Ceramic AC
C8915 9DK001-42157 J 0.1 25V Ceramic AC
C8916 9DK001-42115 J 10p 50V Ceramic AC
C8917 9DK001-42156 J 1 10V Ceramic AC
C8918 9DK001-42157 J 0.1 25V Ceramic AC
C8919 9DK001-40110 J 68 4V Electrolytic AM
C8920 9DK001-42115 J 10p 50V Ceramic AC
C8921 9DK001-40091 J 100 4V Electrolytic AF
C8922 9DK001-42162 J 0.33 10V Ceramic AB
C8923 9DK001-42157 J 0.1 25V Ceramic AC
C8924 9DK001-42157 J 0.1 25V Ceramic AC
C8925 9DK001-42160 J 10 6.3V Ceramic AB
C8927 9DK001-40091 J 100 4V Electrolytic AF
C8928 9DK001-40091 J 100 4V Electrolytic AF
C8930 9DK001-42157 J 0.1 25V Ceramic AC
C8931 9DK001-42161 J 0.047 25V Ceramic AB
C8932 9DK001-42156 J 1 10V Ceramic AC
RESISTORS
R8001 9DK001-51030 J 10k 1/16W Chip AD
R8002 9DK001-50149 J 0 1/16W Chip1608 AB
R8003 9DK001-50179 J 2.2k 1/16W Chip 1608 AA
R8004 9DK001-50149 J 0 1/16W Chip1608 AB
R8008 9DK001-51030 J 10k 1/16W Chip AD
R8011 9DK001-51045 J 100 1/16W Chip AB
R8017 9DK001-50183 J 4.7k 1/16W Chip 1608 AA
R8018 9DK001-50186 J 22k 1/16W Chip 1608 AA
R8022 9DK001-51030 J 10k 1/16W Chip AD
R8025 9DK001-51030 J 10k 1/16W Chip AD
R8026 9DK001-51037 J 6.8k 1/16W Chip AD
R8028 9DK001-50149 J 0 1/16W Chip1608 AB
R8029 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8032 9DK001-50150 J 10 1/16W Chip 1608 AA
R8035 9DK001-50149 J 0 1/16W Chip1608 AB
R8036 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8037 9DK001-50159 J 22 1/16W Chip 1608 AA
R8038 9DK001-50150 J 10 1/16W Chip 1608 AA
R8039 9DK001-50150 J 10 1/16W Chip 1608 AA
R8040 9DK001-50044 J 68 1/10W Chip 2125 AB
R8041 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8042 9DK001-50159 J 22 1/16W Chip 1608 AA
R8045 9DK001-50044 J 68 1/10W Chip 2125 AB
R8046 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8047 9DK001-50159 J 22 1/16W Chip 1608 AA
R8048 9DK001-50044 J 68 1/10W Chip 2125 AB
R8054 9DK001-50149 J 0 1/16W Chip1608 AB
R8063 9DK001-50236 J 910 1/16W Chip1608 AB
R8064 9DK001-50213 J 2k 1/16W Chip1608 AB
R8067 9DK001-51037 J 6.8k 1/16W Chip AD
R8069 9DK001-50149 J 0 1/16W Chip1608 AB
R8073 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8074 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8075 9DK001-50159 J 22 1/16W Chip 1608 AA
R8080 9DK001-50044 J 68 1/10W Chip 2125 AB
R8083 9DK001-50159 J 22 1/16W Chip 1608 AA
R8088 9DK001-50044 J 68 1/10W Chip 2125 AB
R8091 9DK001-50159 J 22 1/16W Chip 1608 AA
R8096 9DK001-50044 J 68 1/10W Chip 2125 AB
R8097 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8104 9DK001-50149 J 0 1/16W Chip1608 AB
R8107 9DK001-50149 J 0 1/16W Chip1608 AB
R8109 9DK001-51037 J 6.8k 1/16W Chip AD
R8110 9DK001-51037 J 6.8k 1/16W Chip AD
R8114 9DK001-50303 J 39 1/10W Chip 2125 AA
R8117 9DK001-50298 J 120 1/4W Chip 3216 AB
R8121 9DK001-50320 J 3.9 1/4W Chip 3216 AA
R8122 9DK001-50320 J 3.9 1/4W Chip 3216 AA
R8134 9DK001-50149 J 0 1/16W Chip1608 AB
R8138 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8139 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8140 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8143 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8157 9DK001-50159 J 22 1/16W Chip 1608 AA
R8161 9DK001-50149 J 0 1/16W Chip1608 AB
R8162 9DK001-50183 J 4.7k 1/16W Chip 1608 AA
R8165 9DK001-50181 J 3.3k 1/16W Chip 1608 AA
R8166 9DK001-50149 J 0 1/16W Chip1608 AB
R8170 9DK001-50149 J 0 1/16W Chip1608 AB
R8172 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8174 9DK001-50149 J 0 1/16W Chip1608 AB
R8176 9DK001-50224 J 150 1/4W Chip 3216 AB
R8178 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8180 9DK001-50149 J 0 1/16W Chip1608 AB
R8201 9DK001-50149 J 0 1/16W Chip1608 AB
R8202 9DK001-50110 J 0 1/10W Chip2125 AB
R8298 9DK001-50110 J 0 1/10W Chip2125 AB
R8299 9DK001-50110 J 0 1/10W Chip2125 AB
R8310 9DK001-50110 J 0 1/10W Chip2125 AB
R8314 9DK001-50110 J 0 1/10W Chip2125 AB
R8500 9DK001-50149 J 0 1/16W Chip1608 AB
R8502 9DK001-50121 J 10 1/10W Chip 2125 AB
R8503 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8509 9DK001-50149 J 0 1/16W Chip1608 AB
R8511 9DK001-50149 J 0 1/16W Chip1608 AB
R8512 9DK001-50149 J 0 1/16W Chip1608 AB
R8513 9DK001-50149 J 0 1/16W Chip1608 AB
R8521 9DK001-51030 J 10k 1/16W Chip AD
R8552 9DK001-50161 J 47 1/16W Chip 1608 AA
R8654 9DK001-50204 J 150 1/16W Chip 1608 AA
R8688 9DK001-50149 J 0 1/16W Chip1608 AB
R8690 9DK001-50173 J 470 1/16W Chip 1608 AA
R8692 9DK001-50149 J 0 1/16W Chip1608 AB
R8693 9DK001-50149 J 0 1/16W Chip1608 AB
R8694 9DK001-50149 J 0 1/16W Chip1608 AB
R8695 9DK001-50149 J 0 1/16W Chip1608 AB
R8696 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8697 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8698 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8699 9DK001-50185 J 10k 1/16W Chip 1608 AA
R8700 9DK001-50218 J 20k 1/16W Chip 1608 AA
R8701 9DK001-50257 J 75 1/16W Chip 1608 AA
R8800 9DK001-50149 J 0 1/16W Chip1608 AB
R8801 9DK001-50205 J 1.8k 1/16W Chip 1608 AA
R8867 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8868 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8869 9DK001-50275 J 6.8 1/10W Chip 2125 AB
R8977 9DK001-50165 J 100 1/16W Chip 1608 AA
R8994 9DK001-50236 J 910 1/16W Chip1608 AB
R8995 9DK001-50199 J 2.15k1/16W Chip1608 AB
R8996 9DK001-50149 J 0 1/16W Chip1608 AB
R8997 9DK001-50149 J 0 1/16W Chip1608 AB
R8998 9DK001-50177 J 1k 1/16W Chip 1608 AA
R8999 9DK001-50303 J 39 1/10W Chip 2125 AA
