KURZBESCHREIBUNG DER OPTIK-EINHEIT
Layout für richtige Einrichtung der optischen Komponenten und Teile (Draufsicht)
Projektionslinse
Relaislinse 3
Relaislinse 2
Relaislinse 1
M5 Al-vergüteter Spiegel B M4 Al-vergüteter Spiegel R
Fliegenauge-Objektiv (Ausgang)
Reflektor B
Reflektor G Reflektor R
Fliegenauge-Objektiv
(Eingang)
Lichtquelle (Lampe)
L2
L2
L1
M3
M2
