Sharp XG-C55X Service Manual

172
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
XG-C55X
RUNTKA058WJZZ
AC INLET UNIT
DIODES
D701 95KUBA0011AK J 1SS133 AB
å Z701 95KUER0002ZZ J Varistor,ENE471D-10A AD
COILS
å L701 95KUKZ1189ZZ J Core, TC25T-5025RT AL
å L702 95KUKZ1189ZZ J Core, TC25T-5025RT AL
CAPACITORS
å C701 95KUGFM224KR J 0.22 275V Film AD
å C702 95KUGFM474KR J 0.47 275V Film AG
å C766 95KUGFM224KR J 0.22 275V Film AD
å C767 95KUGCM222BJ J 2200p Ceramic AD
å C768 95KUGCM222BJ J 2200p Ceramic AD
RESISTORS
å R701 95KUEFB680AY J 1M 1/2W Metal Film AD
å R702 95KUEZ0817ZZ J 3.9 2.4W FuseResistor AG
MISCELLANEOUS PARTS
å F701 95KPJCTP1002 J Fuse, 10A/250V 215010 AF
å RL701 95KPHZ0205ZZ J Relay, AL
DG12D1-0(M) II 0.25W
CN701 95KPZZ1018ZZ J Connector, 3pin(Inlet) AP
M1909-B
CN702 95KPKZ1291ZZ J Connector, 3pin, AD
3-1123724-2
CN703 95KPKZ1220ZZ J Connector, 2pin, AC
B02B-XASK-1
CN709 95KEDB7781ZZ J Lead, LC302-7505 AF
MD702 95KGZZ5491ZZ J Insulator, LC108-3002 AE
MT701 95KLRZ7027ZQ J Angle, LC302-5001 AF
SC701 95KRAA3060AZ J ScrewX2 AB
SC702 95KRAB3060AB J ScrewX2 AA
SC703 95KRAZ4141ZT J Screw AC
RUNTKA026WJN1
FAN UNIT
INTEGRATED CIRCUITS
IC381 VHiTDA7056A-1 J TDA7056A AP
IC7201 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC7202 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC7203 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC7204 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC7205 VHiPQ20WZ11-1Y J PQ20WZ1U AF
TRANSISTORS
Q7201 VS2SA1036KR-1Y J 2SA1036KT146R AC
Q7202 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D7201 VHDDAN202K/-1Y J DAN202KT146 AB
D7202 VHDDAN202K/-1Y J DAN202KT146 AB
D7203 VHDDAN202K/-1Y J DAN202KT146 AB
D7204 VHDDAN202K/-1Y J DAN202KT146 AB
D7205 VHDDAN202K/-1Y J DAN202KT146 AB
D7206 VHDDAN202K/-1Y J DAN202KT146 AB
D7207 VHDDAN202K/-1Y J DAN202KT146 AB
D7208 VHDDAN202K/-1Y J DAN202KT146 AB
D7209 VHDDAN202K/-1Y J DAN202KT146 AB
CAPACITORS
C831 VCKYCY1EF104ZY J 0.1 25V Ceramic AC
C382 VCEASM1CW107MYJ 100 16V Electrolytic AD
C384 VCEASM1CW106MYJ 10 16V Electrolytic AC
C385 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7201 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7202 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7203 VCEASM1CW107MYJ 100 16V Electrolytic AD
C7204 VCEASM1CW476MYJ 47 16V Electrolytic AC
C7205 VCEASM1CW476MYJ 47 16V Electrolytic AC
C7206 VCEASM1CW476MYJ 47 16V Electrolytic AC
C7207 VCEASM1CW476MYJ 47 16V Electrolytic AC
C7208 VCEASM1CW476MYJ 47 16V Electrolytic AC
C7209 VCEASM1CW226MYJ 22 16V Electrolytic AC
C7210 VCE9PF1CW336MY J 33 16V Elect. (N.P) AD
RESISTORS
R381 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R382 VRS-TX2HF8R2JY J 8.2 1/2W Metal Oxide AB
R384 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R7202 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7203 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R7204 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R7206 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R7207 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R7209 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7210 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R7211 VRS-CY1JF302FY J 3k 1/16W Metal Oxide AA
R7212 VRS-CY1JF104FY J 100k 1/16W Metal Oxide AA
R7215 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7216 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R7217 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R7219 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R7220 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R7222 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7223 VRS-CY1JF682FY J 6.8k 1/16W Metal Oxide AA
R7224 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide AA
R7225 VRS-CY1JF823FY J 82k 1/16W Metal Oxide AA
R7227 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R7229 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7230 VRS-CY1JF682FY J 6.8k 1/16W Metal Oxide AA
R7231 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R7232 VRS-CY1JF105FY J 1M 1/16W Metal Oxide AA
R7233 VRS-CY1JF183FY J 18k 1/16W Metal Oxide AA
R7234 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R7235 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R7236 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R7237 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
