Sharp XG-C55X Service Manual

174
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
XG-C55X
RDENCA044WJZZ
POWER UNIT(Continued)
TRANSFORMERS
å T701 95K829205039 J Transformer, STTX10 AH
T702 95KUKZ1187ZZ J Core, TSN27T-08101 AR
å T703 95K829205038 J Transformer, PTTX88 AM
CONTROL
VR701 95KUFBA224DB J Control, 220k AC
EVN DJA A03 BE5(224)
CAPACITORS
C705 95KUGA0439ZZ J 3.3 400V Electrolytic AE
C706 95KUGDB680BN J 150 6.3V Electrolytic AD
C707 95KUGXGFD104 J 0.1 50V Ceramic AB
C708 95KUGXGFD104 J 0.1 50V Ceramic AB
C712 95KUGZ1336ZZ J 2.2 450V Film AM
C713 95KUGXGCF102 J 1000p 50V Ceramic AB
C714 95KUGXAED474 J 0.47 25V Ceramic AC
C715 95KUGXGCF103 J 0.01 50V Ceramic AB
C716 95KUGXKEF224 J 0.22 25V Ceramic AC
C717 95KUGXGCF103 J 0.01 50V Ceramic AB
C718 95KUGXGFD333 J 0.033 25V Chip AB
C719 95KUGXGCF102 J 1000p 50V Ceramic AB
C720 95KUGA0441ZZ J 39 35V Electrolytic AD
C721 95KUGCU681BP J 1000p 1kV Ceramic AD
C722 95KUGDZ420BM J 330 420V Electrolytic AW
C723 95KUGCU471JR J 1000p 1kV Ceramic AC
C725 95KUGCU472BW J 4700p 1kV Ceramic AD
C726 95KUGA0441ZZ J 39 35V Electrolytic AD
C727 95KUGCV221JS J 100p 2kV Ceramic AC
C728 95KUGXGCF472 J 4700p 50V Ceramic AB
C730 95KUGXGCF102 J 1000p 50V Ceramic AB
C731 95KUGXAED224 J 0.22 25V Ceramic AB
C732 95KUGXAED474 J 0.47 25V Ceramic AC
C733 95KUGXGFD104 J 0.1 25V Ceramic AB
C734 95KUGXGCF152 J 1500p 50V Ceramic AB
C736 95KUGXKJT102 J 1000p 630V Ceramic AC
C737 95KUGDD470AQ J 470 25V Electrolytic AE
C738 95KUGDD470AQ J 470 25V Electrolytic AE
C739 95KUGDD470AQ J 470 25V Electrolytic AE
C741 95KUGDD470AQ J 470 25V Electrolytic AE
C743 95KUGDC102AQ J 1000 16V Electrolytic AD
C744 95KUGXGFD104 J 0.1 25V Ceramic AB
C745 95KUGA0249ZZ J 100 10V Electrolytic AC
C746 95KUGA0249ZZ J 100 10V Electrolytic AC
C747 95KUGA0437ZZ J 68 25V Electrolytic AD
å C755 95KUGCZ472HF J 4700p Ceramic AD
C757 95KUGXGFD104 J 0.1 25V Ceramic AB
å C761 95KUGCZ472HF J 4700p Ceramic AD
C762 95KUGXKMS101 J 100p 500V Ceramic AE
C763 95KUGXKMS101 J 100p 500V Ceramic AE
C764 95KUGXKNC684 J 0.68 16V Ceramic AB
C7701 95KUGXKKD106 J 10 25V Ceramic AG
C7702 95KUGXKHB106 J 10 10V Ceramic AD
C7703 95KUGXGCC104 J 0.1 16V Ceramic AB
C7704 95KUGXGFD473 J 0.047 16V Ceramic AB
C7705 95KUGXKHB105 J 1 16V Ceramic AC
C7706 95KUGXGFD104 J 0.1 25V Ceramic AB
C7707 95KUGXKHB106 J 10 10V Ceramic AD
C7708 95KUGXGCC683 J 0.047 16V Ceramic AB
RESISTORS
J701 95KUEXCAP000 J Jumper AB
J702 95KUEXCAP000 J Jumper AB
J7701 95KUEXBAF000 J 0 1/16W Chip AB
J7702 95KUEXBAF000 J 0 1/16W Chip AB
R703 95KUEXBAF221 J 220 1/16W Chip AB
R704 95KUEXBAF122 J 1.2k 1/16W Chip AB
R705 95KUEYCH1002 J 100k 1/16W Chip AB
R706 95KUEYCH1002 J 100k 1/16W Chip AB
R708 95KUEYCH1201 J 12k 1/16W Chip AB
R710 95KUEGGR15BL J 0.15 5W Cement AE
R711 95KUEXDAJ100 J 10 1/4W Chip AB
R712 95KUEXDAJ100 J 10 1/4W Chip AB
R713 95KUEYBD4703 J 470k 1/4W Chip AB
R714 95KUEYBD4703 J 470k 1/4W Chip AB
R715 95KUEYBD3903 J 390k 1/4W Chip AB
R716 95KUEYBA1502 J 15k 1/16W Chip AB
R717 95KUEYBD6803 J 680k 1/4W Chip AB
R718 95KUEYBD5603 J 560k 1/4W Chip AB
R719 95KUEYBD5603 J 560k 1/4W Chip AB
R720 95KUEYBA1302 J 13k 1/16W Chip AB
R721 95KUEXBAF181 J 180 1/16W Chip AB
R722 95KUEXBAF223 J 22k 1/16W Chip AB
R723 95KUEXBAF103 J 10k 1/16W Chip AB
R724 95KUEXBAF681 J 680 1/16W Chip AB
R725 95KUEXDAJ563 J 56k 1/4W Chip AB
R726 95KUEXDAJ563 J 56k 1/4W Chip AB
R727 95KUEXDAJ563 J 56k 1/4W Chip AB
R728 95KUEXDAJ563 J 56k 1/4W Chip AB
R729 95KUEXBAF103 J 10k 1/16W Chip AB
R731 95KUEXBAF000 J 0 1/16W Chip AB
R734 95KUEGGR15BL J 0.15 5W Cement AE
R735 95KUEFE154EG J 150k 2W Metal Film AC
R736 95KUEXDAJ563 J 56k 1/8W Chip AB
R737 95KUEXDAJ563 J 56k 1/8W Chip AB
R738 95KUEXDAJ563 J 56k 1/8W Chip AB
R739 95KUEBCR47AG J 0.47 1/2W FuseResistor AD
R740 95KUEXJAPR22 J 0.22 1/2W Chip AC
R741 95KUEBC3R3AG J 3.3 1/2W FuseResistor AD
R746 95KUEXDAJ000 J 0 1/4W Chip AB
R747 95KUEXDAJ100 J 10 1/4W Chip AB
R748 95KUEXDAJ151 J 150 1/4W Chip AB
R749 95KUEYBA1000 J 100 1/16W Chip AB
R750 95KUEYBA3300 J 330 1/16W Chip AB
R751 95KUEXBAF472 J 4.7k 1/16W Chip AB
R752 95KUEXBAF391 J 390 1/16W Chip AB
R753 95KUEXBAF473 J 47k 1/16W Chip AB
R754 95KUEXBAF822 J 8.2k 1/16W Chip AB
R756 95KUEXBAF222 J 2.2k 1/16W Chip AB
R757 95KUEXBAF000 J 0 1/16W Chip AB
R758 95KUEXBAF122 J 1.2k 1/16W Chip AB
R759 95KUEYBG2202 J 22k 1/8W Chip AB
R760 95KUEYBG4701 J 4.7k 1/4W Chip AB
R761 95KUEXBAF122 J 1.2k 1/4W Chip AB
R762 95KUEXBAF104 J 100k 1/16W Chip AB
R765 95KUEXBAF152 J 1.5k 1/16W Chip AB
R766 95KUEXBAF122 J 1.2k 1/16W Chip AB
R767 95KUEYCH2703 J 270k 1/16W Chip AB
R768 95KUEXBAF122 J 1.2k 1/16W Chip AB
R772 95KUEXBAF103 J 10k 1/16W Chip AB
R773 95KUEXBAF103 J 10k 1/16W Chip AB
R774 95KUEXBAF103 J 10k 1/16W Chip AB
R775 95KUEBCR10AG J 1 1/2W FuseResistor AE
R782 95KUEXBAF122 J 1.2k 1/16W Chip AB
R783 95KUEXBAF122 J 1.2k 1/16W Chip AB
R784 95KUEXDAJ563 J 56k 1/8W Chip AB
R785 95KUEXDAJ153 J 15k 1/8W Chip AB
R786 95KUEXBAF103 J 10k 1/16W Chip AB
R787 95KUEXBAF122 J 1.2k 1/16W Chip AB
R790 95KUEXBAF000 J 0 1/16W Chip AB
R7701 95KUEXBAF123 J 12k 1/16W Chip AB
R7702 95KUEXBAF123 J 12k 1/16W Chip AB
R7703 95KUEXBAF682 J 6.8k 1/16W Chip AB
R7704 95KUEXBAF153 J 15k 1/16W Chip AB
R7705 95KUEXBAF102 J 1k 1/16W Chip AB
R7706 95KUEYCH2701 J 2.7k 1/16W Chip AB
R7707 95KUEYCH1201 J 1.2k 1/16W Chip AB
R7708 95KUEXBAF123 J 12k 1/16W Chip AB
R7709 95KUEXBAF102 J 1k 1/16W Chip AB
R7710 95KUEYCH1501 J 1.5k 1/16W Chip AB
R7711 95KUEYCH1001 J 1k 1/16W Chip AB
R7712 95KUEXBAF103 J 10k 1/16W Chip AB
R7713 95KUEXBAF682 J 6.8k 1/16W Chip AB
R7714 95KUEXBAF103 J 10k 1/16W Chip AB
R7715 95KUEXDAJ121 J 120 1/8W Chip AB
R7716 95KUEXDAJ100 J 10 1/16W Chip AB
