Sharp XG-MB55X - REMOVING OF MAJOR PARTS; Lamp Unit and Top Body Removal

16
XG-MB55X
2. Removing the top body
2-1. Remove 8 top body fixing screws to detach the Top body.
REMOVING OF MAJOR PARTS
1. Removing the lamp door and the lamp unit
1-1. Loosen the lamp door fixing screw. Lift off the lamp door.
1-2. Remove 2 lamp unit fixing screws to detach the lamp unit.
Top Body
Bottom Body
2-1
2-1
1-1
1-2
1-2
Lamp Door
Lamp Unit
