Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
23
XG-MB55X
OPTICAL MECHANISM PARTS
3 CCAPHA024WJSA J Lens Cap Ass’y AG
4 CCHSKA019WEF9 J Optical Mechanism Unit
4-1 LCHSKA019WJF1 J Engine Base BG
4-2 LHLDZA572WJKZ J Mirror Holder AH
4-3 LHLDZA573WJKZ J Rod Holder Base AK
4-4 LHLDZA574WJKZ J Rod Holder Cover AH
4-5 CFiLWA095WEF0 J C/W Ass’y
4-5-1 PFiLWA095WEF0 J Color Wheel
4-5-2 LHLDZA690WJFW J C/W Holder AN
4-5-3 PSHEGA043WJKZ J C/W Thermal PAD AF
4-5-4 XBBS920P05000 J Screw, x3 AB
4-6 MSPRCA062WJFJ J Spring AB
4-7 MSPRPA061WJFW J Plastic Lens Spring AE
4-8 MSPRPA070WJFW J Rod Spring, x2
4-9 PCOVPA028WJSA J Focus Ring AN
4-10 PCOVPA029WJSA J Zoom Ring AM
4-11 PCOVZA056WJFW J Engine Cover AF
4-12 PCOVZA073WJKZ J Lamp House
4-13 PDUC-A064WJKZ J Exhaust Duct AR
4-15 PLNS-A055WJZZ J Projection Lens BV
4-16 PLNS-A056WJZZ J Plastic Lens AX
4-17 PLNS-A057WJZZ J Illmi Lens 1 AR
4-18 PLNS-A058WJZZ J Illmi Lens 2 AS
4-19 PLNS-A059WJZZ J Rod BF
4-20 PMiR-A071WJZZ J Refrect Mirror AS
4-21 PSLDPA036WJFW J Projction Lens Aperture AF
4-22 PSLDPA050WJFW J DMD Aperture AN
4-23 PSLDPA038WJFW J Rod Aperture AD
4-24 PSLDPA039WJFW J Illmi Aperture 1 AF
4-25 PSLDPA040WJFW J Illmi Aperture 2 AG
4-26 PSLDPA042WJFW J House Shading board AE
4-27 PSPAZA769WJZZ J Dust Proof Spacer AF
4-29 XBBSN30P06000 J Screw, M3*6 x13 AA
4-30 XBBSN30P10000 J Screw for CW Holder, x2 AA
4-31 XBPS830P08JS0 J
Screw, Projction Lens x4 Mirror x2
AB
4-32 XEBSN30P08000 J Screw, Duct AA
4-34 TLABZB026WJZZ J Mecha No Label AE
4-35 TLABZB027WJZZ J Optical Model Label AB
6 DUNTKD140WEF0 J DMD Unit BT
7 DUNTKD141WEF0 – Photosensor Unit —
16 LHLDZA612WJFW J Backer Plate AL
18 LX-BZA110WJF7 J Screw for DMD, x4 AC
19 MSPRCA062WJFJ J Spring For DMD, x4 AB
22 NFANSA019WJZZ J Blow Fan Unit BB
27 PRDARA223WJFW J DMD Heat Sink AV
28 PSHEGA040WJZZ J Thermal Pad AE
32 PSPAZA768WJZZ J Back Plt Sheet AD
To Next Page
