Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
21
XG-MB55X
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
The list of PWB parts is referred to in the XR-20X Service Manual.
DUNTKD139FMG0 J MAIN Unit CV
DUNTKD140WEF0 J DMD Unit BT
DUNTKD141WEF0 – PHOTOSENSOR Unit —
DSETUD147FMF9 J BALLAST POWER Ass’y CA
DUNTKD147WEF1 – BALLAST POWER Unit —
(Order the BALLAST POWER Ass’y (DSETUD147FMF9)
when replacing the ballast power unit.)
DUNTKD148WEF0 J BALLAST CONTROL Unit BE
DUNTKD164WEF0 – R/C Unit —
PARTS LIST
PARTS REPLACEMENT
Parts marked with "å" are important for maintaining the safety of
the set. Be sure to replace these parts with specified ones for main-
taining the safety and performance of the set.
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★ MARK: SPARE PARTS-DELIVERY SECTION
CABINET AND MECHANICAL PARTS
1 DBDYTA148WEF0 J Top Body Ass’y
1-1 Not Available – Top Body —
1-2 HDECPA027WJSA J LED Cover AD
1-3 HiNDPB309WJSC J Operation Cover AH
1-4 JBTN-A463WJSA J Power Button AF
2 Not Available – Bottom Body Ass’y —
2-1 CDORUA053WEF0 J Lamp Door Ass’y
2-1-1 Not Available – Lamp Door —
2-1-2 LX-BZ3274CEFN J Lamp Door Screw AE
2-1-3 XRESJ30-06000 J E-Ring AA
2-1-4 PSLDHA036WJFW J Door Shield AE
2-2 DBDYUA185WEF0 J Bottom Body Ass’y
2-2-1 Not Available – Bottom Body —
2-2-3 LX-NZ3144CEFW J Screw, Ceiling x4 Door x1 AC
2-3 GLEGPA030WJSA J Rear ADJ AK
2-4 GLEGPA036WJSA J Front ADJ AP
2-5 HDECPA028WJSA J R/C Cover AE
2-6 XEBSN30P08000 J Screw, Front ADJ Fix AA
4 Refer to Optical Mechanism Parts
5 AN-XR20LP – Lamp Unit (Option) —
8 DSETUD147FMF9 J BALLAST POWER Ass’y CA
8-1 DUNTKD147WEF1 – BALLAST POWER Unit -
(Order the Ballast Power Ass’y (DSETUD147FMF9)
When replacing the ballast Power unit (DUNTKD147WEF1))
8-2 DUNTKD148WEF0 J BALLAST Control Unit BE
9 DUNTKD164WEF0 – R/C Unit —
11 DUNTKD139FMG0 J MAIN Unit CV
11-1 PSLDMA722WJFW J Shield AL
11-2 PSLCMA726WJFW J MAIN PWB Shield AF
11-3 PSPAZA913WJKZ J Shield Spacer AB
12 HiNDPB667WJZZ J PSB Label (55XK)
13 LHLDZA579WJKZ J Speaker Holder AH
14 LHLDZA580WJKZ J Support, x2 AD
15 LHLDZA590WJKZ J PWB Support AD
17 LX-BZ3100CEF7 J Screw, Shield x7 MAIN PWB x2 AA
20 NFANRA053WJ00 J Exhaust Fan for Lamp AX
21 NFANRA054WJ00 J Exhaust Fan for Power, x2 AT
23 PCOVNA008WJZZ J Power Unit Duct B AE
24 PCOVNA009WJZZ J Power Unit Duct C AE
25 PCOVWA004WJKZ J Power Insulator (Front) AH
26 PCOVWA005WJKZ J Power Insulator (Rear) AH
29 PSLDMA720WJFW J Ballast Shield (Top) AM
30 PSLDMA721WJFW J Ballast Shield (Bottom) AV
31 PSPAGA276WJZZ J Fan Rubber, x3 AP
33 PZETKA128WJKZ J Power Insulator (Bottom) AN
34 QCNW-D515WJQZ J LF Wire AG
35 QCNW-D518WJQZ J EA Wire AM
36 QCNW-D575WJPZ J Baimetal Wire AR
39 RSP-ZA085WJQZ J Speaker AP
41 XBBSN30P08000 J Screw, Inlet AA
42 XBPS830P08JS0 J Screw, x2 AB
43 XEBSN30P12000 J Screw, x19 AA
44 TLABZA956WJZZ J WEEE Mark (55XE/55XK) AB
45 LX-NZ3095CEFN J Shaft, x2 AB
46 RH-HXA025WJPZ J Thermistor
47 LHLDW1226CEZZ J Wire Holder AC
48 PSPAZA875WJKZ J Spacer, x2 AC
