20
XG-MB55X
Command description
Control Command Parameter Return
Disabling function BKLM _0 OKorERR
Enabling function BKLM _1 OKorERR
Keystone correction range expansion BKST ＊＊＊＊ OKorERR
(-200 - +200)
Vertical compression adjustment BKVO ＊＊＊＊ OKorERR
(-300 - +300)
■Keystone correction range expansion and vertical compression adjustment function
The variable range of the keystone can be expanded to over the user adjustable range by using
the following RS-232C commands. In addition, the vertical compression can be adjusted.
