-22
Terminal on the
projector
INPUT 1, 2
AUDIO INPUT
INPUT 1, 2
INPUT 1, 2
INPUT3
INPUT4
AUDIO INPUT
AUDIO INPUT
AUDIO OUTPUT
OUTPUT
Equipment
Computer
Audio-visual
equipment
Amplifier
Monitor
Terminal on
connected equipment
RGB
output terminal
Audio
output terminal
Component
video
output terminal
Terminal
for using
the
dedicated
cable
Video
output terminal
S-video
output terminal
Audio
output terminal
Terminal
for using
the
dedicated
cable
Audio
input terminal
RGB input
terminal
Cable
RGB cable (supplied)
ø3.5 mm stereo audio cable (commercially available)
3 RCA (Component) to 15-pin D-sub cable (optional: AN-C3CP)
Connect with the cable adaptor, etc.
Video cable (commercially available)
S-video cable (commercially available)
ø3.5 mm minijack to RCA audio cable
(commercially available)
Connect with the cable adaptor, etc.
ø3.5 mm minijack to RCA audio cable
(commercially available)
RGB cable (commercially available)
Samples of Cables for Connection
•For more details of connection and cables, refer to the opeation manual of the connecting equipment.
•You may need other cables or connectors not listed below.
Cable adaptor (commercially available)
Cable adaptor
(commercially available)
3 RCA (Component)
to 15-pin D-sub cable
(optional: AN-C3CP)
Dedicated cable
ø3.5 mm minijack to RCA audio cable
(commercially available)
Dedicated cable
XG-MB70X_E_P21_28.p65 2004.8.6, 11:58 AM22
