ENGLISH
E-26
References
- Specifications -
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
„
General
„
Amplifier
„
CD player
„
Tuner
„
Speaker
Power source AC 110, 127, 220, 230 - 240 V, 50/60 Hz
Power
consumption
30 W
Dimensions Width: 230 mm (9-1/16")
Height: 128 mm (5-1/16")
Depth: 293 mm (11-9/16")
Weight 3.0 kg (6.6 lbs.)
Output power MPO: 30 W (15 W + 15 W) (10 % T.H.D.)
RMS: 20 W (10 W + 10 W) (10 % T.H.D.)
Output terminals Speakers: 8 ohms
Headphones: 16 - 50 ohms (recommended:
32 ohms)
CD digital output (optical)
Input terminals Video/Auxiliary (audio signal): 500 mV/47
kohms
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 88 - 108 MHz
AM: 531 - 1,602 kHz
Type 2-way type speaker system
Tweeter
10 cm (4") Woofer
Maximum input
power
20 W
Rated input power 10 W
Impedance 8 ohms
Dimensions Width: 140 mm (5-9/16")
Height: 263 mm (10-3/8")
Depth: 187 mm (7-3/8")
Weight 1.5 kg (3.3 lbs.)/each
