General Information
- Controls and Indicators -
Controls and Indicators (continued)
„
Rear panel
Reference page
1. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.AM Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
3.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
4.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
5. CD Digital Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 24
7. AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9
8. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9
9.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
„
Speaker system
1. Tweeter
2.Woofer
3.Bass Reflex Duct
4.Speaker Terminals
Placing the speaker system:
There is no distinction between the right and the left speakers.
2
1
3
4
5
6
8
9
7
4
3
2
1
The rating label is located
on the bottom of the unit.
Speaker grilles are removable:
Make sure nothing comes into contact with the
speaker diaphragms when you remove the
speaker grilles.
Left speaker Right speaker
