Sharp XL-30H Service Manual

– 5 –
XL-30H/30W
NAMES OF PARTS
XL-30H/30W
1
2
3
4
6
7
8
9
5
10
11
12
13
14
15
16
21
22
23
24
25
26
27
28
17
18
19
20
1
2
3
2
1
4
3
5
XL-30H
XL-30W
■ Front panel
1. Timer Indicator
2. Record Indicator
3. Sleep Indicator
4. (CD) Repeat Indicator
5. (CD) Play Indicator
6. (CD) Random Indicator
7. (CD/TUNER) Memory Indicator
8. FM Stereo Mode Indicator
9. FM Stereo Indicator
10. CD Compartment
11. On/Stand-by Button
12. (CD/TAPE) Stop Button
(TUNER) Memory Clear Button
13. Record Pause Button
14. Bass/Treble Selector Button
15. Memory/Set Button
16. Clock/Timer/Sleep Button
17. Band Selector Button
18. (CD) Review Button
(TAPE) Rewind Button
(TUNER) Tuning Down Button
19. Function Selector Button
20. Headphone Socket
21. CD Eject Button
22. Remote Control Sensor
23. Volume Select Button
24. (CD) Play/Pause Button
(TAPE) Play Button
25. Jog Dial
26. (CD) Cue Button
(TAPE) Fast Forward Button
(TUNER) Tuning Up Button
27. Volume/Jog Dial Selector Button
28. Cassette Compartment
■ Rear panel
1. AC Power Input Socket
2. FM/AM Loop Aerial Socket
3. S
p
eaker Terminals
■ Rear panel
1. Voltage Selector
2. AC Power Input Socket
3. FM 75 ohms Aerial Socket
4. AM Loop Aerial Socket
5. Speaker Terminals
