Sharp XL-60H User Manual

32
SPECIFICATIONS
As a part of our policy of continuous improvement, SHARP reserves the right to make design and
specification changes for product improvement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be some deviations from these values
in individual units.
● Cassette deck section
Frequency
response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 50 dB
Wow and flutter: 0.25 % (WRMS)
● Speaker section
Type: 2-way [10 cm (4") woofer and
1.5 cm (9/16") tweeter]
Rated input
power: 20 W
Maximum input
power: 40 W
Impedance: 4 ohms
Dimensions: Width; 160 mm (6-5/16")
Height; 240 mm (9-1/2")
Depth; 190 mm (7-7/16")
Weight: 1.8 kg (4.0 lbs.)/each
Type: 2-way [10 cm (4") woofer and
2.5 cm (1") semi dome
tweeter]
Rated input
power: 20 W
Maximum input
power: 40 W
Impedance: 4 ohms
Dimensions: Width; 160 mm (6-5/16")
Height; 240 mm (9-1/2")
Depth; 189 mm (7-1/16")
Weight: 2.4 kg (5.3 lbs.)/each
● General
Power source: AC 230 V, 50 Hz
Power
consumption: 50 W
Dimensions: Width; 160 mm (6-5/16")
Height; 241 mm (9-1/2")
Depth; 298 mm (11-3/4")
Weight: 3.6 kg (7.9 lbs.)
● Amplifier section
Output power: RMS; 40 W (20 W + 20 W)
(10 % T.H.D.)
Output terminals: Speakers; 4 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
CD digital output (optical)
Input terminals: Video/Auxiliary (audio signal);
500 mV/47 k ohms
● Tuner section
Frequency range: FM; 87.5-108 MHz
AM; 522-1,620 kHz
● Compact disc player section
Type: Compact disc player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A converter: 1-bit D/A converter
Filter: 8-times oversampling digital
filter
Frequency
response: 20 - 20,000 Hz
Wow and flutter: Unmeasurable
(less than 0.001% W. peak)
CP-XL60H
CP-XL70H
*60H/70H(SUK)28-32 00.1.5, 11:41 AM32

Sharp XL-60H Specifications

General

Brand	Sharp
Model	XL-60H
Category	Stereo System
Language	English
